ADVANCE INFORMATION
VCT 69xyP
Volume 1: General Description
Micronas November 3, 2004; 6251-644-1-1AI
1-55
3.12.Pin Connections and Short Description
NC = not connected
LV = if not used, leave vacant
OBL = obligatory; connect as described in circuit
diagram
IN = Input Pin
ANA = Analog Pin
OUT = Output Pin
SUPPLY = Supply Pin
VCTP Pin No.
Pin Name
Type
Connection
Short Description
PLQFP
208-1
(If not used)
1 656O6
P4_6
TDOFW
IN/OUT LV Digital 656 Bit 6 Output
Port 4, Bit 6 Input/Output
JTAG Interface Data Output (firmw. Controler)
2 656O5
P4_5
TDIFW
IN/OUT LV Digital 656 Bit 5 Output
Port 4, Bit 5 Input/Output
JTAG Interface Data Input (firmw. Controler)
3 656O4
P4_4
TMSFW
IN/OUT LV Digital 656 Bit 4 Output
Port 4, Bit 4 Input/Output
JTAG Interface Mode Select Input (fw. Contr.)
4 656O3
P4_3
TCLK
IN/OUT LV Digital 656 Bit 3 Output
Port 4, Bit 3 Input/Output
JTAG Interface Clock Input (TV Controler)
5 656O2
P4_2
TDO
IN/OUT LV Digital 656 Bit 2 Output
Port 4, Bit 2 Input/Output
JTAG Interface Data Output (TV Controler)
6 656O1
P4_1
TDI
IN/OUT LV Digital 656 Bit 1 Output
Port 4, Bit 1 Input/Output
JTAG Interface Data Input (TV Controler)
7 656O0
P4_0
TMS
IN/OUT LV Digital 656 Bit 0 Output (LSB)
Port 4, Bit 0 Input/Output
JTAG Interface Mode Select Input (TV Contr.)
8 RESETQ IN/OUT OBL Reset
Input/Output
9 AIN1R IN GND Analog Audio 1 Input, Right
10 AIN1L IN GND Analog Audio 1 Input, Left
11 AIN2R IN GND Analog Audio 2 Input, Right
12 AIN2L IN GND Analog Audio 2 Input, Left
13 AIN3R IN GND Analog Audio 3 Input, Right
14 AIN3L IN GND Analog Audio 3 Input, Left
15 AIN4R IN GND Analog Audio 4 Input, Right
16 AIN4L IN GND Analog Audio 4 Input, Left
17 VREFAU ANA OBL Reference Voltage, Audio
18 VSUP8.0AU SUPPLY OBL Supply Voltage Analog Audio, 8.0 V
19 GNDA SUPPLY OBL Ground Analog Audio, Platform Ground
20 SGND ANA OBL Analog Signal GND
