2.6.3. Pin Description (Continued)
7368868E STMicroelectronics Confidential 35/709
STi5516 Pin list
Confidential
Table 16: Interrupt pins
Pin Location I/O Function
Pad
type
INTERRUPT[3:0]
A b
I/O External interrupts C4
a. 5 V tolerant
b. T1, T2, T3 and T4.
Table 17: Analog audio DAC (digital-to-analog converter) pins
Pin Location I/O Function
OUTPLEFT AC3 O Left channel, differential positive current output
OUTMLEFT AB1 O Left channel, differential negative current output
OUTPRIGHT AC4 O Right channel, differential positive current output
OUTMRIGHT AB4 O Right channel, differential negative current output
Table 18: Analog video DAC pins
Pin Location I/O Function
ROUT AF11 O Red output
GOUT AE11 O Green output
BOUT AD12 O Blue output
COUT AF9 O Chroma output
CVOUT AD10 O Composite video output
YOUT AE10 O Luma output
Table 19: Digital video pins
Pin Location I/O Function
Pad
type
NOT_HSYNC
A
AE20 I/O Horizontal sync C4
EVENNOTODD
a
AF20 I/O Vertical sync C4
a. 5 V tolerant
