16
LC-32HT1U
20. Remove the 2 lock screws j and detach the SP (R) Terminal PWB.
21. Remove the 3 lock screws k and detach the Speaker Brackt (R).
22. Remove the 2 lock screws l and detach the SP (L) Terminal PWB.
23. Remove the 3 lock screws ; and detach the Speaker Brackt (L).
24. Remove the 2 lock screws
31
and detach the R/C, LED PWB.
25. Remove the 2 lock screws
32
and detach the LCD Panel Module.
!"#$
To Next Page
