Sharp LC-32LE265T - Other Unit; Outline; PWB Unit

LC-32LE265T / LC-40LE265T
iii
OUTLINE
OUTLINE
PWB UNIT
40LE265T
Ref No. Part No. ĞƐĐƌŝƉƟŽŶ
DKEYMG567FM01 MAIN hŶŝƚ
RDENCA474WJPZ Power UŶŝt
DUNTKG463FM01 LED/IR hŶit
RUNTKB281WJZZ LED Bar (A)
RUNTKB282WJZZ LED Bar (B)
32LE265T
Ref No. Part No. ĞƐĐƌŝƉƟŽŶ
DKEYMG567FM02 MAIN hŶŝƚ
DUNTKG409FM02 Power UŶŝt
DUNTKG463FM01 LED/IR hŶit
RUNTKB283WJZZ LED Bar (A)
RUNTKB284WJZZ LED Bar (B)
OTHER UNIT
40LE265T
Ref No. Part No. ĞƐĐƌŝƉƟŽŶ
RLCDTA325WJQZ PANEL HIRAKI
CLCDTA373WE09 PANEL ASSEMBLY
32LE265T
Ref No. Part No. ĞƐĐƌŝƉƟŽŶ
R1LK315T3HB60W PANEL HIRAKI
CLCDTA377WE08 PANEL ASSEMBLY
