Sharp LC-32LE265T User Manual

LC-32LE265T / LC-40LE265T
6 – 25
[4] R/C LED UNIT ( LC-32/40LE265T )
A
C
B
D
E
F
G
H
2 109
8
7
6
54
3
1
R159
1.5K
R154 10K
R158
820
R151
100
R152
10K
Q152
2SC3928AR
LEDCONT
Q153
2SC3928AR
LEDCONT
C157
10u
CKZ
C158
10u
CKZ
*D153 PXA194WJQZ
Green
D152 PXA193WJQZ
RED
RMC151 UA088WJ
123
P151
NB150WJ
TOMAINRA
1
D+3.3V
2
GND
3
R/C
4
LEDG
5
LEDRP
DUNTKGWE
RC.LEDUNIT

R/C.LED
0
0.2
0.7
0
2.3
0
