STANDBY_POW
*S105
KA037WJ
POW
2
4
3
1
KEY_1
*R104
12K
*R103
8.2K
KEY_2
*R101
8.2K
S108 KA050WJ
1
VOL UP
2
INPUT/MENU
3
CH DOWN
4
CH UP
5
GND
6
VOL DOWN
TO MAIN4(CPU)
(QPWBXG512WJT1)
DUNTKFWE
MAIN11(KEY)
