Sharp LC-32LE265T

PARTS GUIDE
No. SZ4M66LC-32/40LE265T
LED BACKLIGHT TV
MODEL:
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-32LE265T / LC-40LE265T
LC-32LE265T
LC-40LE265T
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
[3] DKEYMG567FM02 / 01 (MAIN Unit)
[4] LED /IR UNIT ( DUNTKG463FM01)
[5] CABINET AND MECHANICAL
PARTS ( LC-40LE265T )
[6] CABINET AND MECHANICAL
PARTS ( LC-32LE265T )
[7] LCD PANEL ( LC-40LE265T )
[8] LCD PANEL ( LC-32LE265T )
[9] SUPPLIED ACCESSORIES
[10] PACKING PARTS ( NOT REPLACE-
MENT ITEM )
[11] EXPLODE VIEW ( LC-40LE265T )
[12] EXPLODE VIEW ( LC-32LE265T )
