Sharp LC-32LE340E Service Manual

LC-32LE340/343
LC-40LE340/343
REF No. PARTS DESCRIPTION *
PRICE
CODE
R227 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R228 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R229 30000727 RES SMD 1/10W 47K J 0805 ROHS G --
R230 30001160 RES MO 2W 0.33R J RoHS G --
R231 30025823 RES SMD 1/10W 15K F 0805 ROHS G --
R232 30020394 FERRIT SMD 330/100MHZ 0.1R M 1.5A 805RO G --
R233 30000818 RES SMD 1/10W 8.2K J 0805 ROHS G --
R234 30000818 RES SMD 1/10W 8.2K J 0805 ROHS G --
R235 30000818 RES SMD 1/10W 8.2K J 0805 ROHS G --
R236 30000818 RES SMD 1/10W 8.2K J 0805 ROHS G --
R237 30000818 RES SMD 1/10W 8.2K J 0805 ROHS G --
R238 30000818 RES SMD 1/10W 8.2K J 0805 ROHS G --
R239 30000818 RES SMD 1/10W 8.2K J 0805 ROHS G --
R240 30000494 RES SMD 1/10W 120R J 0805 ROHS G --
R243 30012355 RES SMD 1/10W 6.8K F 0805 RoHS G --
R244 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R245 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R246 30000644 RES SMD 1/10W 3K J 0805 ROHS G --
R247 30012852 RES SMD 1/10W 3.9K F 0805 ROHS G --
R248 30000717 RES SMD 1/10W 470R J 0805 ROHS G --
R252 30000464 RES SMD 1/10W 100R J 0805 ROHS G --
R253 30001734 RES SMD 1/10W 0R 0805 ROHS G --
R255 30000664 RES SMD 1/10W 3.3K J 0805 ROHS G --
R256 30000747 RES SMD 1/10W 560R J 0805 ROHS G --
R257 30000626 RES SMD 1/10W 270R J 0805 ROHS G --
R258 30000747 RES SMD 1/10W 560R J 0805 ROHS G --
R259 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R260 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R261 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R262 30006462 RES SMD 1/10W 22R J 0805 ROHS G --
R263 30000480 RES SMD 1/10W 100K J 0805 ROHS G --
R266 30000664 RES SMD 1/10W 3.3K J 0805 ROHS G --
R301 30000529 RES SMD 1/10W 1.5K J 0805 ROHS G --
R305 30000727 RES SMD 1/10W 47K J 0805 ROHS G --
R306 30000727 RES SMD 1/10W 47K J 0805 ROHS G --
R307 30000506 RES SMD 1/10W 120K J 0805 ROHS G --
R308 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R309 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R310 30000774 RES SMD 1/10W 680R J 0805 ROHS G --
R311 30000612 RES CF 1/4W 2.4K J G --
R312 30020394 FERRIT SMD 330/100MHZ 0.1R M 1.5A 805RO G --
R313 30000797 RES SMD 1/10W 75R J 0805 ROHS G --
R314 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R315 30064316 RES SMD 1/8W 3.3K F (0805) ROHS G --
R316 30015473 RES SMD 1/10W 150R F 0805 ROHS G --
R317 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R318 30007789 RES SMD 1/10W 27K F 0805 ROHS G --
R320 30000638 RES CF 1/4W 270K J ROHS G --
R322 30020394 FERRIT SMD 330/100MHZ 0.1R M 1.5A 805RO G --
R324 30025823 RES SMD 1/10W 15K F 0805 ROHS G --
R325 30000668 RES SMD 1/10W 33K J 0805 ROHS G --
R329 30000455 RES SMD 1/8W 10R J (1206) ROHS G --
R330 30000626 RES SMD 1/10W 270R J 0805 ROHS G --
R331 30000626 RES SMD 1/10W 270R J 0805 ROHS G --
R337 30000529 RES SMD 1/10W 1.5K J 0805 ROHS G --
R338 30070785 RES MG SAFE 1/2W 7.8M J NEW ROHS G --
R400 30000609 RES SMD 1/10W 2.2R J 0805 ROHS G --
R401 30064316 RES SMD 1/8W 3.3K F (0805) ROHS G --
REF No. PARTS DESCRIPTION *
PRICE
CODE
R403 30000517 RES SMD 1/10W 15R J 0805 ROHS G --
R406 30000609 RES SMD 1/10W 2.2R J 0805 ROHS G --
R407 30000751 RES SMD 1/10W 5.6K J 0805 ROHS G --
R409 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R410 30000653 RES SMD 1/10W 33R J 0805 ROHS G --
R411 30000735 RES SMD 1/10W 4.7R J 0805 ROHS G --
R412 30000735 RES SMD 1/10W 4.7R J 0805 ROHS G --
R414 30000609 RES SMD 1/10W 2.2R J 0805 ROHS G --
R417 30064582 RES SMD 1/8W 18K F 0805 ROHS G --
R418 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R419 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R420 30000735 RES SMD 1/10W 4.7R J 0805 ROHS G --
R421 30000735 RES SMD 1/10W 4.7R J 0805 ROHS G --
R422 30000609 RES SMD 1/10W 2.2R J 0805 ROHS G --
R424 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R425 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R426 30064582 RES SMD 1/8W 18K F 0805 ROHS G --
R427 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R428 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R429 30007026 RES SMD 1/10W 5.1K J 0805 ROHS G --
F100 30028356 FUSE SAFE 3.15A 250V (RADIAL) ROHS G --
F101 30028356 FUSE SAFE 3.15A 250V (RADIAL) ROHS G --
J103 30002583 KISA DEVRE TELI 0.6MM G --
J104 30002583 KISA DEVRE TELI 0.6MM G --
J105 30002583 KISA DEVRE TELI 0.6MM G --
J107 30002583 KISA DEVRE TELI 0.6MM G --
J108 30002583 KISA DEVRE TELI 0.6MM G --
J110 30002583 KISA DEVRE TELI 0.6MM G --
J111 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J113 30002583 KISA DEVRE TELI 0.6MM G --
J114 30002583 KISA DEVRE TELI 0.6MM G --
J115 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J116 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J118 30002583 KISA DEVRE TELI 0.6MM G --
J119 30002583 KISA DEVRE TELI 0.6MM G --
J120 30002583 KISA DEVRE TELI 0.6MM G --
J121 30002583 KISA DEVRE TELI 0.6MM G --
J122 30002583 KISA DEVRE TELI 0.6MM G --
J124 30002583 KISA DEVRE TELI 0.6MM G --
J125 30002583 KISA DEVRE TELI 0.6MM G --
J126 30002583 KISA DEVRE TELI 0.6MM G --
J127 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J129 30002583 KISA DEVRE TELI 0.6MM G --
J130 30002583 KISA DEVRE TELI 0.6MM G --
J132 30002583 KISA DEVRE TELI 0.6MM G --
J133 30002583 KISA DEVRE TELI 0.6MM G --
J134 30002583 KISA DEVRE TELI 0.6MM G --
J136 30002583 KISA DEVRE TELI 0.6MM G --
J137 30002583 KISA DEVRE TELI 0.6MM G --
J138 30002583 KISA DEVRE TELI 0.6MM G --
J139 30002583 KISA DEVRE TELI 0.6MM G --
J140 30002583 KISA DEVRE TELI 0.6MM G --
J141 30002583 KISA DEVRE TELI 0.6MM G --
J143 30001734 RES SMD 1/10W 0R 0805 ROHS G --
J144 30002583 KISA DEVRE TELI 0.6MM G --
J145 30002583 KISA DEVRE TELI 0.6MM G --
MISCELLANEOUS PARTS
129
LC-32LE340/343
LC-40LE340/343
