Sharp LC-32LE340E Service Manual

LC-32LE340/343
LC-40LE340/343
REF No. PARTS DESCRIPTION *
PRICE
CODE
J146 30002583 KISA DEVRE TELI 0.6MM G --
J147 30002583 KISA DEVRE TELI 0.6MM G --
J149 30002583 KISA DEVRE TELI 0.6MM G --
J150 30002583 KISA DEVRE TELI 0.6MM G --
J153 30002583 KISA DEVRE TELI 0.6MM G --
J154 30002583 KISA DEVRE TELI 0.6MM G --
J155 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J157 30002583 KISA DEVRE TELI 0.6MM G --
J158 30002583 KISA DEVRE TELI 0.6MM G --
J159 30002583 KISA DEVRE TELI 0.6MM G --
J160 30002583 KISA DEVRE TELI 0.6MM G --
J161 30002583 KISA DEVRE TELI 0.6MM G --
J162 30002583 KISA DEVRE TELI 0.6MM G --
J163 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J164 30002583 KISA DEVRE TELI 0.6MM G --
J166 30002583 KISA DEVRE TELI 0.6MM G --
J167 30002583 KISA DEVRE TELI 0.6MM G --
J169 30002583 KISA DEVRE TELI 0.6MM G --
J170 30002583 KISA DEVRE TELI 0.6MM G --
J174 30002583 KISA DEVRE TELI 0.6MM G --
J175 30002583 KISA DEVRE TELI 0.6MM G --
J176 30002583 KISA DEVRE TELI 0.6MM G --
J179 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J180 30001734 RES SMD 1/10W 0R 0805 ROHS G --
J181 30001734 RES SMD 1/10W 0R 0805 ROHS G --
J182 30002583 KISA DEVRE TELI 0.6MM G --
J183 30001734 RES SMD 1/10W 0R 0805 ROHS G --
J187 30001734 RES SMD 1/10W 0R 0805 ROHS G --
MD101 35027467 GROUND TERMINAL 4 MM GND-8 ROHS G --
MD102 35027587 GROUND TERMINAL 5 MM GND-20 ROHS G --
MD103 35027587 GROUND TERMINAL 5 MM GND-20 ROHS G --
MD200 35027467 GROUND TERMINAL 4 MM GND-8 ROHS G --
PG3 40045272 SPACER SUPPORT DCBS-8 RoHS V0 G --
PG4 40045272 SPACER SUPPORT DCBS-8 RoHS V0 G --
PL100 30070259 CONNHEADERSAFE 2PV0 7.92 R/A 3.5mmBLKRHS G --
PL100- 35000176 EYELET BR 2*3MM ROHS G --
PL100- 35000176 EYELET BR 2*3MM ROHS G --
PL101 30070232 CONNHEADER SAFE 2P V0 7.92SIDE 3.5mm RHS G --
PL101- 35000176 EYELET BR 2*3MM ROHS G --
PL101- 35000176 EYELET BR 2*3MM ROHS G --
PL205 30067935 CONN HEADER 2X14P 2.54 W/LOCK SIDE RoHS G --
PL306 30048870 CONN HEADER 12P 2.5MM SIDE WHT ROHS G --
S104 30002583 KISA DEVRE TELI 0.6MM G --
S117 30002583 KISA DEVRE TELI 0.6MM G --
S202 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S203 30002583 KISA DEVRE TELI 0.6MM G --
S204 30002583 KISA DEVRE TELI 0.6MM G --
S300 30001735 RES SMD 1/8W 0R 1206 ROHS G --
S301 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S303 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S304 30001734 RES SMD 1/10W 0R 0805 ROHS G --
TH103 30067963 RES THE SAFE 10R/2.3A NTC 7mm RAD RoHS G --
TH105 30067963 RES THE SAFE 10R/2.3A NTC 7mm RAD RoHS G --
TR100 30068375 TRF PFC SAFE 250uH PQ35 10mm PW0426/32R G --
TR100- 35000176 EYELET BR 2*3MM ROHS G --
TR100- 35000176 EYELET BR 2*3MM ROHS G --
TR100- 35000176 EYELET BR 2*3MM ROHS G --
TR100- 35000176 EYELET BR 2*3MM ROHS G --
REF No. PARTS DESCRIPTION *
PRICE
CODE
TR100- 35000176 EYELET BR 2*3MM ROHS G --
TR101 30068003 Choke Coil 150uH 3A K 20x20x10.5 RoHS G --
TR200 30068583 TRF SMT SAFE RES PW04 EEM4344 10mmDRIN R G --
TR300 30068115 TRF SMT SAFE 42''Slim EPC19 St-By 10mmRo G --
IC100 30053502 IC PFC FAN7529 SO8 ROHS G --
IC200 30015087 IC SAFE OPTOCOUPLER TCET1102G G --
IC201 30015087 IC SAFE OPTOCOUPLER TCET1102G G --
IC202 30065433 IC PFM CONT FAN7621 SOP16 RoHS G --
IC300 30015087 IC SAFE OPTOCOUPLER TCET1102G G --
IC301 30063524 IC STAND-BY FSQ211 DIP8 ROHS G --
IC302 30015087 IC SAFE OPTOCOUPLER TCET1102G G --
IC400 30067808 IC PWM CONT NCP1579 SO8 ROHS G --
IC401 30066849 TR DNMOS FDS8984 7A/30V SO8 RoHS G --
IC402 30067808 IC PWM CONT NCP1579 SO8 ROHS G --
IC403 30066849 TR DNMOS FDS8984 7A/30V SO8 RoHS G --
Q100 30060725 TR NMOS STP9NK50ZFP 7.2A/500V TO220FROHS G --
Q102 30068728 TR NMOS FQT1N60C 0.2A/600V SOT223 ROHS G --
Q200 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q201 30060725 TR NMOS STP9NK50ZFP 7.2A/500V TO220FROHS G --
Q202 30060725 TR NMOS STP9NK50ZFP 7.2A/500V TO220FROHS G --
Q209 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q210 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q211 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q212 30029322 TR NMOS FDV303N 0.68A/25V SOT23 ROHS G --
Q213 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q300 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q301 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q302 30001452 TR PBJT BC327 0.5A/45V TO92 ROHS G --
Q303 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q304 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
D102 30057252 DIODE SMD RS1002FL 0.5A/200V SOD123FL RO G --
D105 30036849 DIODE BRIDGE GBU8K 8A/800V 150A ROHS G --
D106 30001319 DIODE RL207 2A/1000V 70A DO-15 ROHS G --
D107 30051096 DIODE SMD ZEN C6.2V SOD123 ROHS G --
D109 30001319 DIODE RL207 2A/1000V 70A DO-15 ROHS G --
D111 30014352 DIODE MUR460 4A/600V DO-27 ROHS G --
D112 30001319 DIODE RL207 2A/1000V 70A DO-15 ROHS G --
D119 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D150 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D200 30008996 IC VREF TL431SAMF2 ADJ %1 SOT23 R G --
D201 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D202 30038481 DIODE SMD ZEN C6.8V SOD123 ROHS G --
D203 30038498 DIODE SMD ZEN C18V SOD123 ROHS G --
D204 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D206 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D207 30038495 DIODE SMD ZEN C22V SOD123 ROHS G --
D208 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D209 30019996 DIODE SMD BAV70 215mA/75V 4A SOT23 RoHS G --
D210 30038497 DIODE SMD ZEN C3.9V SOD123 ROHS G --
D213 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
LC-40LE340/343 POWER SUPPLY
17PW07
INTEGRATED CIRCUITS
TRANSISTORS
DIODES
130
LC-32LE340/343
LC-40LE340/343
