LC-32LE340/343
LC-40LE340/343
REF No. PARTS DESCRIPTION *
PRICE
CODE
D214 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D215 30066697 DIODE SCH SR110 1A/100V/30A DO41 ROHS G --
D218 30048782 DIODE SCH STPS20H100CFP20A/100V TO220ROH G --
D219 30001291 DIODE HER107 1A/800V 30A DO41 ROHS G --
D220 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D222 30039202 DIODE SCH STPS2045CFP 20A/45V TO220 ROHS G --
D228 30066697 DIODE SCH SR110 1A/100V/30A DO41 ROHS G --
D238 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D239 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D300 30057252 DIODE SMD RS1002FL 0.5A/200V SOD123FL RO G --
D301 30008996 IC VREF TL431SAMF2 ADJ %1 SOT23 R G --
D302 30059220 DIODE SMD RS1008FL 0.5A/800V SOD123FL RO G --
D303 30038498 DIODE SMD ZEN C18V SOD123 ROHS G --
D304 30057252 DIODE SMD RS1002FL 0.5A/200V SOD123FL RO G --
D305 30001345 DIODE ZEN 6.8V 0.5W SOD27 ROHS G --
D308 30066697 DIODE SCH SR110 1A/100V/30A DO41 ROHS G --
D309 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D401 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D404 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
FR100 30006712 FERRIT BEAD AXI 70/100M 3A 3.5x4.7Roh G --
FR101 30006712 FERRIT BEAD AXI 70/100M 3A 3.5x4.7Roh G --
FR400 30024779 FERRIT SMD 50R/100MHZ 0.4R M 3A 1206 ROH G --
FR401 30024779 FERRIT SMD 50R/100MHZ 0.4R M 3A 1206 ROH G --
FR402 30024779 FERRIT SMD 50R/100MHZ 0.4R M 3A 1206 ROH G --
FR403 30006712 FERRIT BEAD AXI 70/100M 3A 3.5x4.7Roh G --
FR404 30006712 FERRIT BEAD AXI 70/100M 3A 3.5x4.7Roh G --
FR405 30024779 FERRIT SMD 50R/100MHZ 0.4R M 3A 1206 ROH G --
L101 30069003 LINE FILTER SAFE 2*11mH 1A 0R17 10mm ROH G --
L102 30069003 LINE FILTER SAFE 2*11mH 1A 0R17 10mm ROH G --
L104 20594513 CN.ASY.FerriteBead(FTZ)Axial8x17x7(MAKAR G --
L105 20594513 CN.ASY.FerriteBead(FTZ)Axial8x17x7(MAKAR G --
L201 30067937 Choke Coil 1uH 5A Axial M 0.7R 10x5.5 Ro G --
L202 30067937 Choke Coil 1uH 5A Axial M 0.7R 10x5.5 Ro G --
L205 30001735 RES SMD 1/8W 0R 1206 ROHS G --
L300 30067937 Choke Coil 1uH 5A Axial M 0.7R 10x5.5 Ro G --
L302 30024779 FERRIT SMD 50R/100MHZ 0.4R M 3A 1206 ROH G --
L306 30002016 COIL AXI 150UH 85MA K 15R 2.7X7 RO G --
L401 30062563 Choke coil Toroid Safe 33uH 3A K 6x12Ro G --
L402 30001735 RES SMD 1/8W 0R 1206 ROHS G --
L413 30062563 Choke coil Toroid Safe 33uH 3A K 6x12Ro G --
L414 30001735 RES SMD 1/8W 0R 1206 ROHS G --
C100 30067966 CAP MKP SAFE 220NF275VMACX215BOXLEFTBROH G --
C101 30070590 CAPEL 47UF 450VM105C1200mA12.5X40SHALEFT G --
C102 30068025 CAP MKT SAFE 1UF 450V K 15DIPLB TOS RoHS G --
C103 30070590 CAPEL 47UF 450VM105C1200mA12.5X40SHALEFT G --
C105 30067966 CAP MKP SAFE 220NF275VMACX215BOXLEFTBROH G --
C106 30070590 CAPEL 47UF 450VM105C1200mA12.5X40SHALEFT G --
C109 30069935 CAP CER SAFE 1.5NF 4KV M 3.5MMSHARoHS G --
C112 30061026 CAP SMD 1UF 25V K X7R (0805) ROHS G --
C113 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C114 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C115 30068234 CAP MKP SAFE 100NF 275V M X2AC15BOX ROHS G --
C116 30066377 CAP CER 220PF 1KV K YRN 125C(PULSE) ROHS G --
C117 30000263 CAP SMD 56PF 50V J COG (0805) ROHS G --
COILS AND FILTERS
CAPACITORS
REF No. PARTS DESCRIPTION *
PRICE
CODE
C118 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C120 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C121 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C122 30068025 CAP MKT SAFE 1UF 450V K 15DIPLB TOS RoHS G --
C123 30000284 CAP SMD 1NF 50V K X7R (0805) ROHS G --
C124 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C129 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C131 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C133 30068234 CAP MKP SAFE 100NF 275V M X2AC15BOX ROHS G --
C134 30069935 CAP CER SAFE 1.5NF 4KV M 3.5MMSHARoHS G --
C151 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C154 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C155 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C156 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C181 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C190 30069935 CAP CER SAFE 1.5NF 4KV M 3.5MMSHARoHS G --
C191 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C193 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C195 30069935 CAP CER SAFE 1.5NF 4KV M 3.5MMSHARoHS G --
C198 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C200 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C201 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C207 30000309 CAP SMD 2.2NF 50V K X7R (0805) ROHS G --
C208 30070720 CAP EL 560UF 35V M 105C 2150mA10X25SHALE G --
C209 30070744 CAPEL 560UF 25V M105C1050mA 8X20SHALEFT G --
C210 30070745 CAPEL 560UF 50V M105C 1500mA 8X40SHALEFT G --
C211 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C212 30070744 CAPEL 560UF 25V M105C1050mA 8X20SHALEFT G --
C213 30070849 CAP EL 47UF 50V M 105C 90mA 8x7SHARPROHS G --
C214 30068808 CAP MKP 15NF 630Vdc/622VppJ15LBENRoHS G --
C216 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C217 30000309 CAP SMD 2.2NF 50V K X7R (0805) ROHS G --
C218 30070720 CAP EL 560UF 35V M 105C 2150mA10X25SHALE G --
C219 30061026 CAP SMD 1UF 25V K X7R (0805) ROHS G --
C220 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C221 30070745 CAPEL 560UF 50V M105C 1500mA 8X40SHALEFT G --
C224 30070744 CAPEL 560UF 25V M105C1050mA 8X20SHALEFT G --
C228 30000265 CAP SMD 560PF 50V J COG (0805) ROHS G --
C230 30010561 CAP SMD 220NF 50V K X7R (0805) ROHS G --
C231 30000256 CAP SMD 470PF 50V J COG (0805) ROHS G --
C300 30070849 CAP EL 47UF 50V M 105C 90mA 8x7SHARPROHS G --
C302 30070849 CAP EL 47UF 50V M 105C 90mA 8x7SHARPROHS G --
C304 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C307 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C308 30070849 CAP EL 47UF 50V M 105C 90mA 8x7SHARPROHS G --
C309 30066237 CAP MKP 4.7NF 630VDC/622VPP K 7.5BOXROHS G --
C315 30070589 CAPEL 4.7UF 450VM 105C70mA10x12.5SHALEFT G --
C319 30067959 CAP EL 1000UF 16V M 105C 8x20LEFTBENDROH G --
C323 30070746 CAPEL 470UF 10V M105C 640mA 8X12 SHALEFT G --
C325 30070849 CAP EL 47UF 50V M 105C 90mA 8x7SHARPROHS G --
C326 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C400 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C401 30070746 CAPEL 470UF 10V M105C 640mA 8X12 SHALEFT G --
C402 30070746 CAPEL 470UF 10V M105C 640mA 8X12 SHALEFT G --
C403 30061026 CAP SMD 1UF 25V K X7R (0805) ROHS G --
C404 30015459 CAP SMD 470NF 25V K X7R (0805) ROHS G --
C405 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C406 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
131
LC-32LE340/343
LC-40LE340/343
