CHAPTER 9. PARTS GUIDE
[1] SPARE PARTS LIST
MODEL: LC-32LE40E
Item Parts Code Sharp Code Description
705TQBSKJ11001 9JR7050001012 SKD KITS
044T3121510515 9JR4400000431 SPONGE
SP01 078G0110574 YA 9JR7800000157 SPEAKER 16 OHM 11W 132X27MM - NO
0Q1G 930 8 47 XL 9JR0100000816 SCREW 3X8
ECN601 395G801304XM25 9JR3950000007 HARNESS 4P(2506)-B&R+B&W 650+330MM
ECN402 395G801413XM34 9JR3950000008 HARNESS 13P(2008)-5P+7P 280+550MM
P33T0178PBC 1X0100 9JR3300000002 LENS _DOUBLE_430
P33T0297 1 1C0100 9JR3300000108 LENS_IR_42_LED_SHP
P34T0935ADTA1T0230 9JR3400000129 BEZEL
P34T0936ADT04T0230 9JR3400000130 REAR COVER
Q16G000103002700TS 9JR1600000037 SPONGE
Q36G 600 18111 TS 9JR3600000007 NON-WOVEN FABRIC CLOTH 0.25 0.3
Q36G 600 35 3 TS 9JR3600000011 NON-WOVEN FABRIC CLOTH 0.3 0.3
Q36G 600 35 3 TS 9JR3600000011 NON-WOVEN FABRIC CLOTH 0.3 0.3
Q36G060003001000TS 9JR3600000008 NON-WOVEN FABRIC
Q36G060003600900TS 9JR3600000013 NON-WOVEN FABRIC
Q36G060003600900TS 9JR3600000013 NON-WOVEN FABRIC
Q40G000284315A 9JR4000000660 FEATURE-POP LABEL
Z52G120102600000GB 9JR5200000075 TAPE_DOUBLE
KEPFBAB4 9JR9900000544 KEY BOARD
CN0101 033G8032 7F S HR 9JR3300000107 CONNECTOR 7P 1.25
U102 056G 669 60 9JR5600000314 TOUCH KEY IT7235BFN-3108/AX (R) QFN-24
R112 061G0402101 JF 9JR6100002269 RST CHIPR 100 OHM +-5% 1/16W FENGHUA
R117 061G04021651FF 9JR6100002273 RST 0402 1.65K 1% 1/16W FENGHUA
R118 061G04021651FF 9JR6100002273 RST 0402 1.65K 1% 1/16W FENGHUA
R124 061G04022201FI 9JR6100002278 RST CHIPR 2.2KOHM +-1% 1/16W TA-I
R116 061G04022201FI 9JR6100002278 RST CHIPR 2.2KOHM +-1% 1/16W TA-I
R122 061G04022941FT 9JR6100002280 RST 0402 2.94K 1% 1/16W
R120 061G04023300FF 9JR6100002282 RST CHIPR 330 OHM +-1% 1/16W FENGHUA
R115 061G04023300FF 9JR6100002282 RST CHIPR 330 OHM +-1% 1/16W FENGHUA
R121 061G04028200FI 9JR6100002296 RST 0402 820R 1% 1/16W
R119 061G04028200FI 9JR6100002296 RST 0402 820R 1% 1/16W
C104 065G040210131J 3 9JR6500001427 CAP CHIP 0402 100P 50V NPO +/-5%
C105 065G040210425K F 9JR6500001429 CHIP 0402 0.1UF 25V X5R
C103 065G040210425K F 9JR6500001429 CHIP 0402 0.1UF 25V X5R
C102 065G040210425K F 9JR6500001429 CHIP 0402 0.1UF 25V X5R
C101 065G040210425K F 9JR6500001429 CHIP 0402 0.1UF 25V X5R
E715 715G5439K01000004I 9JR7150000018 KEY BOARD PCB
IRPFCAA1 9JR9900000543 IR BOARD
U001 056T 627904 9JR5600000318 IR RECEIVER IRM-3638TF16
CN001 033G8032 5F X 9JR3300000036 WAFER 5P 1.25MM S1315-05RVB-S03-K
Q002 057G 477900 T 9JR5700000052 TRA SIG SM BC847C (KEC0) R
R002 061G0603000 JT 9JR6100000620 RST CHIP MAX 0R05 1/10W TZAI YUAN
R006 061G0603101 JF 9JR6100001098 RST CHIPR 100 OHM +-5% 1/10W FENGHUA
R005 061G0603103 JY 9JR6100000732 RST CHIPR 10KOHM £«-5£¥ 1/10W YAGEO
R003 061G0603222 JI 9JR6100002299 RST 0603 2.2K 5% 1/10W
C003 065G060310432K Y 9JR6500000251 CAP 0603 100NF 10% 50V X7R
C001 065G060310512K T 9JR6500000253 CAP 0603 1UF 10% 16V X7R
LED001 081G 15 7 EL 9JR8100000003 CHIP LED WHITE 50-115UMC/343996F/TR8
E715 715G5327R01000004S 9JR7150000017 IR BOARD PCB
705TQBSKJ12001 9JR7050001013 PROCESS BOX
052G 1185 9JR5200000064 MIDDLE TAPE (Y1200141)
