Sharp LC-32LE40E - Chapter 5. Major IC Informations [1] Major IC Information

LC-32LE40E-LC-42LE40E
50
CHAPTER 5. MAJOR IC INFORMATIONS
[1] MAJOR IC INFORMATION
2.1 U401(MT5366CAOU/B)
General Description
The MediaTek MT5365/66 family is a backend decoder and a TV controller and offers high integration for advanced applications. It combines a transport
de-multiplexer, a high definition video decoder, an AC3 audio decoder, a dual-link LVDS/mini-LVDS transmitter, and an NTSC/PAL/SECAM TV decoder
with a 3D comb filter (NTSC/PAL). The MT5365/66 enables consumer electronics manufactures to build high quality, low cost and feature-rich DTV.
World-Leading Audio/Video Technology: The MT5365/66 supports Full-HD MPEG1/2/4/DiviX/VC1/RM/H.264/AVS video decoder standards, and JPEG.
The MT5365/66 also supports MediaTek MDDiTM de-interlace solution can reach very smooth picture quality for motions. A 3D comb filter added to the
TV decoder recovers great details for still pictures. The special color processing technology provides natural, deep colors and true studio quality video.
Also, the MT5365/66 family has built-in high resolution and high-quality audio codec. Rich Features for High Value Products: The MT5365/66 family
enables true singlechip experience. It integrates high-quality HDMI1.3 (partial HDMI1.4), high speed VGA ADC, dual-channel LVDS, USB2.0 receiver,
Ethernet, TCON and panel overdrive.
Key Features
1. Worldwide multi-standard analog TV demodulator
2. A transport demultiplexer
3. A muti-standard video decoder
4. An AC3/MPEG2 audio decoder
5. HDMI1.3 receiver (cover HDMI1.4 partial Spec)
HDMI 1.4
Spec.
Ethernet
Channel
3D over
HDMI
4Kx2K
Audio Return
Channel
Additional
Color Space
Optional Yes No Yes Yes
6. Audio codec
7. TCON
8. Ethernet
9. Panel overdrive control
10. Local dimming
General Features
Host CPU
 ARM1176JZS-756MHz
 16K I-Cache and 16K D-Cache
 14K Boot ROM
 JTAG ICE interface
 Watch Dog timers
Transport Demultiplexer
 New generation 2 demux design
 Supports one serial transport stream input
 Supports ATSC, DVB-T, DVB-C transport stream input
 Support DES / 3-DES / DVB / AES / Multi-2 de-scramblers
 Up to 8 even/odd keys for descrambling
 Supports 32 PID filters and 32 section filters
 Supports 32 PID filters for recording
 Supports hardware CRC-32 check
 Supports PCR recovery function
 Supports a micro-processor for stream process and video start code detection
