Sharp LC-32LE40E - Page 135

LC-32LE40E-LC-42LE40E
135
R1292 061G0402470 JT 9JR6100002289 RST CHIP 47R 1/16W 5% TZAI YUAN
R4151 061G0402470 JT 9JR6100002289 RST CHIP 47R 1/16W 5% TZAI YUAN
R665 061G04024700FT 9JR6100000678 RST CHIP 470R 1/16W 1%
R666 061G04024700FT 9JR6100000678 RST CHIP 470R 1/16W 1%
R1031 061G0402471 JT 9JR6100000880 RST CHIP 470R 1/16W 5% TZAI YUAN
R1030 061G0402471 JT 9JR6100000880 RST CHIP 470R 1/16W 5% TZAI YUAN
R1022 061G0402471 JT 9JR6100000880 RST CHIP 470R 1/16W 5% TZAI YUAN
R1032 061G0402471 JT 9JR6100000880 RST CHIP 470R 1/16W 5% TZAI YUAN
R569 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R643 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R650 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R705 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R714 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R734 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R401 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4245 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4244 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4247 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R527 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R528 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R533 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R539 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R540 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R542 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R549 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R550 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R552 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4243 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R1203 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R1205 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R1258 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R1266 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R1281 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R1282 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R1372 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R1373 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R404 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R406 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R410 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4167 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4179 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4220 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4221 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4222 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4223 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4224 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R4242 061G0402472 JT 9JR6100000615 RST CHIP 4K7 1/16W 5% TZAI YUAN
R1202 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R1211 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R1212 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R1213 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R1214 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R519 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R520 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R536 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R537 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R555 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R601 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R602 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R614 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R1201 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R622 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R617 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R619 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R1191 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R1192 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R1193 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
R1194 061G0402473 JT 9JR6100000616 RST CHIP 47K 1/16W 5% TZAI YUAN
