LC-32LE510
LC-40LE510
1.2 MB60 Placement of Blocks
1.2. MB60 Placement of Blocks
Main IC (U157)
Tuner(TU102)
Nand
Flash
(U162)
SPI
Etherne
t IC
DDR2
DDR2
RAM
LVDS
Connectors
DVD
External
Keyboard
Power Connector
Saw
Filter
Keypad
YPbPr
SAV
HP
HDMI
Connectors
VGA
SCART
Connector
SP
D
I
F
Ethernet
Connector
or
Speake
Led
Inv.
CI Con
nector
