Sharp LC-32LE510E User Manual

97
LC-32LE510
LC-40LE510
MARK *: SPARE DELIVERY SECTION (G: EPC Sharp GmbH)
30071826 TFT 32FHD50HZ ELED LG LC320EUN-SDV1 PL (PANEL DISPLAY LC32LE510) G --
30070539 TFT 40FHD50HZ ELED SAM LTAA400HM13 (PANEL DISPLAY LC40LE510) G --
20565124 CHS.ASSY.17MB60-C4L1211H192322111SC (MAIN BOARD LC32LE510E) G --
20567893 CHS.ASSY.17MB60-C4L1211H192322211V1 (MAIN BOARD LC40LE510E) G --
! 20563052 MD.ASY.17PW07-32" (MB60_SHARP)ROC (POWER SUPPLY LC32LE510E) G --
! 20555233 MD.ASY.17PW07-42" (MB60_SHARP)ROC (POWER SUPPLY C40LE510E) G --
20565400
MD.ASY.17LD98-7-26880 (25/35(SHARP)RED/GR) ( I/R & LED Board With Cable LC-
32LE510) G --
20565404
MD.ASY.17LD98-7-37-42880 (25/35(SHARP)RED/GR) ( I/R & LED Board with cable
LC-40LE510) G --
30069633 MD.ASY-17TK131CY-XX845/860(V5.0 SW ) (Touch pad Board LC-40LE510) G --
U1 30069495 IC LDO AP2111H 3.3V/600MA SOT223 ROHS G --
U3 30060852 IC ANALOG 2:1SWITCH FSA3157 SC70 ROHS
G --
U145 30062776 DIODE ESD AZ1045-04S SOT23-6 ROHS G --
U149 30062763 IC STMPS2161 SOT23-5L ROHS G --
U155 30070284 IC DDR2 64Mx16 W971GG6JB-18 BGA84 ROHS G --
U157 30068667 IC MSD9WB9PX-2-T1 DIVX BGA523 RoHS G --
U157 40043122 SUPER THIN POWDER (20*20*2)Rohs G --
U158 30067466 IC FLASH SPI 8Mb W25Q80BV SO8 ROHS G --
U162 30069934 IC NAND 512Mb K9F1208U0C TSOP48 RoHS G --
U168 30068105 IC AAMP TPA3113 2x6W BTL TSSOP28 ROHS G --
U173 30070995 IC STEP DOWN RT8293A ADJ/3A SO8 RoHS G --
U175 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U176 30066926 IC STEP DOWN MP2012 ADJ/1.5A QFN6 RoHS G --
U178 30057644 IC DOPAMP TL062 SO8 RoHS G --
U180 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U181 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
Q119 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q140 30029775 TR NMOS BSN20 0.17A/50V SOT23 ROHS G --
INTEGRATED CIRCUITS
REF No. PARTS DESCRIPTION *
PRICE
CODE
32LE510E/40LE510E LCD PANEL
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY
PRINTED WIRING BOARDS
LC-32LE510E - MB60
MAIN Unit
TRANSISTORS
REF No.
PARTS
DESCRIPTION
*
PRICE
CODE
Q144 30007800 TR NBJT BF799 0.35A/30V RF SOT23 RoHS G --
Q146 30001458 TR BC858B SMD G --
Q170 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q171 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q173 30001458 TR BC858B SMD G --
Q174 30001458 TR BC858B SMD G --
Q178 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q180 30001458 TR BC858B SMD G --
Q181 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q185 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q186 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q188 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q189 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q190 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q191 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q192 30010733 TR NMOS 2N7002 0.1A/60V SOT23 ROHS G --
Q193 30001458 TR BC858B SMD G --
Q194 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q195 30001458 TR BC858B SMD G --
Q199 30018060 TR PMOS FDC642P -4A/-20V SSOT6 ROHS G --
Q202 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q203 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q204 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q205 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q207 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q208 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q209 30069749 TR NMOS BSH105 1.05A/30V SOT23 ROHS G --
Q210 30010733 TR NMOS 2N7002 0.1A/60V SOT23 ROHS G --
D145 30012411 DIODE SMD BA782 0.1A 35V SOD123 ROHS G --
D165 30042066 DIODE SMDSCH1N5819 1A/40V/25A SOD123ROHS G --
D169 30019996 DIODE BAV70 215mA/75V 4A SOT23 RoHS G --
D171 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D173 30062776 DIODE ESD AZ1045-04S SOT23-6 ROHS G --
D174 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D175 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D176 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D177 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D178 30038478 DIODE SMD ZEN C15V SOD123 ROHS G --
D184 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D185 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D186 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D189 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D191 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D192 30049510 FUSE SAFE SMD 3A 32V DC (1206) ROHS G --
D2 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
D203 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D204 30038502 DIODE SMD ZEN B5.1V SOD123 ROHS G --
D7 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
X2 30057263 XTAL 24MHz 22pF 30ppm 25OhmHC49S SMDROHS G --
L104 30055201 COIL SMD 2.2uH 15mA J 1R15 603 Ro G --
DIODES
PACKAGED CIRCUITS
COILS AND FILTERS
PARTS LISTING
REPLACEMENT PARTS
Replacement parts which have special safety characteristics are identied in this
manual.
Electrical components having such features are identied by in the Replace-
ment Parts Listing.
The use of a substitute replacement part which does not have the same safety
characteristics as the factory recommended is not permitted.
Replacement parts not shown in this service manual may create shock re, or
other hazards.
HOW TO ORDER REPLACEMENT PARTS
To have your order completed promptly and correctly please supply the
following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO.
4. DESCRIPTION 5. CODE 6. QUANTITY
!
