Sharp LC-37XD1E - Page 63

LC-37XD1E/RU
5 – 9
61 AVSS - Analog Ground for IF Part. GND
62 AVSS - Analog Ground for IF Part. GND
63 NC - Not Connected. N.C.
64 NC - Not Connected. N.C.
65 AVSUP - Analog Power Supply +5V. +5V
66 AVSUP - Analog Power Supply +5V. +5V
67 ANA_IN1 + I IF Input 1. SIF-IN
68 ANA_IN - I IF Common (can be Left vacant only if lF input 1 is not used) ANA-IN-
69 ANA_IN2 + I IF Input2 (can be left vacant only if lF input 1 is not used) ANA-IN2+
70 TESTEN - Test Pin (imust be connected to ground) GND
71 XTAL_IN I Crystal Oscillator Input. XTAL-IN
72 XTAL_OUT O Crystal Oscillator Output. XTAL-OUT
73 TP I Test Input. N.C.
74 AUD_CL_OUT O Audio Clock Output (18.432MHz) N.C.
75 NC - Not Connected. N.C.
76 SPDIF_OUT O S/PDIF Output. N.C.
77 DCTRI/O_1 I/O Digital Control Port 1. N.C.
78 DCTRI/O_0 I/O Digital Control Port 0. N.C.
79 ADR_SEL I I2C Address Select. GND
80 STANDBYQ - Standby (active low) +5V
