7. IC3301: FRC RH-IXB064WJ (FRC9429A)
FRAME RATE CONVERTER
Pin No. Pin Name I/O Pin Function
1 NC - No Connection
2 NC - Test, do not use
3 656I1/YIN1 I Digital (luminance) input
4 656I2/YIN2 I Digital (luminance) input
5 VIN I Vertical sync input
6 656I3/YIN3 I Digital (luminance) input
7 656I4/YIN4 I Digital (luminance) input
8 VDDP0 S Supply digital pad (3.3 V)
9 VSSP0 S Supply digital pad (0 V)
10 HIN I Horizontal sync input
11 656I5/YIN5 I Digital (luminance) input
12 656I6/YIN6 I Digital (luminance) input
13 656I7/YIN7 I Digital (luminance) input [MSB]
14 CLKIN I Clock input (max. 81.0 MHz)
15 VDDD0 S Supply digital pad (1.8 V)
16 VSSD0 S Supply digital pad (0 V)
17 AVI I Active video input
18 VDDAPLL S Supply analog PLL (1.8 V)
19 VSSAPLL S Supply analog PLL (0 V)
20 VSSD1 S Supply digital core (0 V)
21 VDDD10 S Supply digital core (1.8 V)
22 VDDD11 S Supply digital core (1.8 V)
23 XIN I Crystal connection 1
24 XOUT O Crystal connection 2
25 VSSP1 S Supply digital pad (0 V)
26 VDDP1 S Supply digital pad (3.3 V)
27 RGBOUT9 O
Tristate (SELOMODE=0)
Digital (red: SELRB=0; blue: SELRB=1;)
Output [MSB](SELOMODE=1)
28 RGBOUT8 O
Tristate (SELOMODE=0)
Digital (red: SELRB=0; blue: SELRB=1;)
Output (SELOMODE=1)
29 RGBOUT7 O
Tristate (SELOMODE=0)
Digital (red: SELRB=0; blue: SELRB=1;)
Output (SELOMODE=1)
30 RGBOUT6 O
Tristate (SELOMODE=0)
Digital (red: SELRB=0; blue: SELRB=1;)
Output (SELOMODE=1)
31 RGBOUT5 O
Tristate (SELOMODE=0)
Digital (red: SELRB=0; blue: SELRB=1;)
output (SELOMODE=1)
32 RGBOUT4 O
Tristate (SELOMODE=0)
Digital (red: SELRB=0; blue: SELRB=1;)
Output (SELOMODE=1)
33 AVO/ITR O
Active video output (CPUIRQ=0)
Interrupt signal output from µC (CPUIRQ=1)
Static 0 (CPUIRQ=2)
Static 1 (CPUIRQ=3)
34 VOUT O Vertical sync output
35 HOUT O Horizontal sync output.
(Synchronized to 40.5-81 MHz CLKOUTSEL72=1)
(Synchronized to 20.25-40.5 MHz
CLKOUTSEL72=0 and CLKOUTSEL=1)
(Synchronized to 15.1875-30.75 MHz
CLKOUTSEL72=0 and CLKOUTSEL=0)
36 CLKOUT O Output clock disabled (CLKOUTON=0)
Output clock (max. 81 MHz) (CLKOUT=1)
(40.5-81 MHz CLKOUT72=1
20.25-40.5 MHz CLKOUT72=0 and CLKOUTSEL=1
1515.1875-30.37 MHz CLKOUT72=0 and
CLKOUTSEL=0)
37 VSSP2 S Supply digital pad (0 V)
38 VDDP2 S Supply digital pad (3.3 V)
39 RESET I Reset input
