Sharp LC-37XD1E - Page 65

LC-37XD1E/RU
5 – 11
40 RGBOUT3 O
Tristate (SELOMODE=0)
Digital (red: SELRB=0; blue: SELRB=1;)
Output (SELOMODE=1)
41 RGBOUT2 O
Tristate (SELOMODE=0)
Digital (red: SELRB=0; blue: SELRB=1;)
Output (SELOMODE=1)
42 RGBOUT1 O
Tristate (SELOMODE=0)
Digital (red: SELRB=0; blue: SELRB=1;)
Output (SELOMODE=1)
43 RGBOUT0 O
Tristate (SELOMODE=0)
Digital (red: SELRB=0; blue: SELRB=1;)
Output [LSB] (SELOMODE=1)
44 YOUT9 O
Tristate (ENITUE=0)
Digital (luminance/green) output [MSB] (ENITUE=1)
45 YOUT8 O
Tristate (ENITUE=0)
Digital (luminance/green) output (ENITUE=1)
46 YOUT7 O
Tristate (ENITUE=0)
Digital (luminance/green) output (ENITUE=1)
47 VDDD2 S Supply digital core (1.8 V)
48 VSSD2 S Supply digital core (0 V)
49 VDDP3 S Supply digital pad (3.3 V)
50 VSSP3 S Supply digital pad (0 V)
51 NC - No Connection
52 YOUT6 O
Tristate (ENITUE=0)
Digital (luminance/green) output (ENITUE=1)
53 YOUT5 O
Tristate (ENITUE=0)
Digital (luminance/green) output (ENITUE=1)
54 VSSP4 S Supply digital pad (0 V)
55 YOUT4 O
Tristate (ENITUE=0)
Digital (luminance/green) output (ENITUE=1)
56 VDDP4 S Supply digital pad (3.3 V)
57 YOUT3 O
Tristate (ENITUE=0)
Digital (luminance/green) output (ENITUE=1)
58 YOUT2 O
Tristate (ENITUE=0)
Digital (luminance/green) output (ENITUE=1)
59 YOUT1 O
Tristate (ENITUE=0)
Digital (luminance/green) output (ENITUE=1)
60 YOUT0 O
Tristate (ENITUE=0)
Digital (luminance/green) output [LSB] (ENITUE=1)
61 CLKF20 O
Output clock 20.25 MHz disabled (CLKF20ON=0)
Output clock 20.25 MHz enabled (CLKF20ON=1)
62 UVOUT9 O
Tristate (ENITUE=0)
Digital (chrominance/blue) output [MSB] (ENITUE=1and SELRB=0)
Digital (chrominance/red) output [MSB] (ENITUE=1and SELRB=1)
63 VSSD30 S Supply digital core (0 V)
64 VSSD31 S Supply digital core (0 V)
65 VDDD30 S Supply digital core (1.8 V)
66 VDDD31 S Supply digital core (1.8 V)
67 UVOUT8 O
Tristate (ENITUE=0)
Digital (chrominance/blue) output (ENITUE=1 and SELRB=0)
Digital (chrominance/red) output (ENITUE=1 and SELRB=1)
68 UVOUT7 O
Tristate (ENITUE=0)
Digital (chrominance/blue) output (ENITUE=1 and SELRB=0)
Digital (chrominance/red) output (ENITUE=1 and SELRB=1)
69 VSSP50 S Supply digital pad (0 V)
70 VSSP51 S Supply digital pad (0 V)
71 VSSP52 S Supply digital pad (0 V)
72 VDDP5 S Supply digital pad (3.3 V)
73 UVOUT6 O
Tristate (ENITUE=0)
Digital (chrominance/blue) output (ENITUE=1 and SELRB=0)
Digital (chrominance/red) output (ENITUE=1 and SELRB=1)
74 NC - No Connection
75 NC - No Connection
76 UVOUT5 O
Tristate (ENITUE=0)
Digital (chrominance/blue) output (ENITUE=1 and SELRB=0)
Digital (chrominance/red) output (ENITUE=1 and SELRB=1)
77 NC - No Connection
