Sharp LC-40D68UT - Outline; Major Service Parts

LC-40D68UT
iv
LC-40D68UT
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB UNIT
OTHER UNIT
IC FOR EXCLUSIVE USE OF THE SERVICE
SERVICE JIGS
Ref No. Parts Code Description
N DUNTKF463FM02 MAIN Unit
N DUNTKF465FM02 TERMINAL Unit
N DUNTKE266FM02 KEY Unit
N DUNTKF096FM01 R/C, LED Unit
N RDENCA393WJQZ POWER Unit
N 9JS-5540T04C04 LCD CONTROL Unit
N 9JS-1940T04001 INVERTER Unit
Ref No. Parts Code Description
N R1LK400D3LF31Z 40" LCD Panel Module Unit
Ref No. Parts Code Description Q’ty
IC602 VHiS24CS02JHES IC R1EX24002ASAS0A 1
IC1610 VHiR24002AS3YS IC R1EX24002ASAS0A 1
IC1611 VHiR24002AS2YS IC R1EX24002ASAS0A 1
IC1612 VHiR24002AS4YS IC R1EX24002ASAS0A 1
IC2002 RH-iXC165WJN5Q IC R5F212A8SNFP 1
IC8451 RH-iXC895WJN1S IC MX25L6405DMI-12G 1
Ref No. Parts Code Description Q’ty
N QCNW-G401WJQZ L=1000mm 4-5pins, Main to Key (KM) 1
N QCNW-H649WJPZ L=1000mm 4pins, Main to Speaker (SP) 1
N QCNW-H762WJQZ L=1000mm 10pins, Main to R/C LED (RA) 1
N QCNW-K865WJQZ L=1000mm 51pins, Main to T-CON (LW) 1
N QCNW-K866WJQZ L=1000mm 12-14pins, Main to Power (PD) 1
N QCNW-K867WJQZ L=1000mm 14pins, Power to Inverter (LB2) 1
