Sharp LC-40D68UT - Chapter 2. Operation Manual; Operation Manual

LC-40D68UT
2 – 1
LC-40D68UT
Service Manual
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL
TV (Front)
OPC indicator
OPC sensor
*
POWER indicator
Remote control sensor
TV (Rear/Side)
*1 External equipment connection.
*2 Button operations.
*3 Connecting the AC cord.
*4 Details on the PC Audio Select function.
• The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
* OPC: Optical Picture Control
POWER button
MENU button
INPUT button
Channel buttons
(CH /)
Volume buttons
(VOL /)
DIGITAL AUDIO OUTPUT terminal
INPUT 7 terminal (HDMI)
INPUT 6 terminal (HDMI)
INPUT 4 terminal (PC-IN)
AUDIO terminal
(shared for INPUT 4 and INPUT 6)*4
Antenna/Cable in
INPUT 1 terminals
INPUT 2 terminals
OUTPUT terminals
INPUT 3
terminals
SERVICE
terminal
INPUT 5
terminal
(HDMI)
AC INPUT
terminal
*1
*2
*3
*1
