1 HDMI CEC TEST Enter HDMI CEC test
2 INSPECT USB TERM Enter Reading inspection of USB memory terminal
3 HDMI EDID WRITE Enter HDMI EDID WRITING
4 MONIDATA READ [TEMP/OPC] OFF MONITOR Temperature/OPC Acquisition tool.
5 CAUSE RESET Enter Reset of standby cause
6 SD CARD TEST Size 1 SD CARD TEST
(*This item is LC-40/46/52LE822E, LC-40/46LU822E only)
7 SD CARD REC SIZE xx SD CARD REC SIZE
(*This item is LC-40/46/52LE822E, LC-40/46LU822E only)
8 RESET OFF SD CARD RESET
(*This item is LC-40/46/52LE822E, LC-40/46LU822E only)
6/21
1 COMP15K ALL ADJ Enter Component 15K picture level adjustment
2 COMP15K MAIN Y GAIN 141 Y GAIN adjustment value
3 COMP15K MAIN CB GAIN 150 Cb GAIN adjustment value
4 COMP15K MAIN CR GAIN 150 Cr GAIN adjustment value
5 COMP15K Y OFFSET 64 Y OFFSET adjustment value
6 COMP15K CB OFFSET 128 Cb OFFSET adjustment value
7 COMP15K CR OFFSET 128 Cr OFFSET adjustment value
7/21
1 HDTV ADJ Enter HDTV video level adjustment
2 HDTV Y GAIN 141 HDTV Y GAIN adjustment value
3 HDTV CB GAIN 150 HDTV Cb adjustment value
4 HDTV CR GAIN 150 HDTV Cr adjustment value
5 HDTV Y OFFSET 64 HDTV Y OFFSET adjustment value
6 HDTV CB OFFSET 128 HDTV Cb OFFSET adjustment value
7 HDTV CR OFFSET 128 HDTV Cr OFFSET adjustment value
8/21
1 ANALOG PC ADJ Enter DVI ANALOG video level adjustment
2 R OFFSET 64 R CUTOFF adjustment value
3 G OFFSET 64 G CUTOFF adjustment value
4 B OFFSET 64 B CUTOFF adjustment value
5 R GAIN 44 R DRIVE adjustment value
6 G GAIN 44 G DRIVE adjustment value
7 B GAIN 44 B DRIVE adjustment value
9/21
1 SCART RGB ADJ Enter SCART RGB level adjustment
2 SCART R CUTOFF 64 SCART R CUTOFF adjustment value
3 SCART G CUTOFF 64 SCART G CUTOFF adjustment value
4 SCART B CUTOFF 64 SCART B CUTOFF adjustment value
5 SCART R GAIN 44 SCART R GAIN adjustment value
6 SCART G GAIN 44 SCART G GAIN adjustment value
7 SCART B GAIN 44 SCART B GAIN adjustment value
10/21
1 VCOM ADJ 0 Common bias adjustment
11/21
1 R GAIN (LO) 0 R DRIVE adjustment value
2 G GAIN (LO) 0 G DRIVE adjustment value
3 B GAIN (LO) 0 B DRIVE adjustment value
4 R GAIN (HI) 0 R DRIVE adjustment value
5 G GAIN (HI) 0 G DRIVE adjustment value
6 B GAIN (HI) 0 B DRIVE adjustment value
12/21
1 MONITOR TIME OUT ON Monitor and the main communication time-out setting
2 MONITOR MAX TEMP 45 MONITOR MAX temperature setting
3 MONITOR EEP READ/WRITE WRITE MONITOR EEPROM READ/WRITE Setting/execution
4 MONITOR EEP ADR 0x 0 MONITOR EEPROM arbitrary addressing
5 MONITOR EEP DATA 0x 0 MONITOR EEPROM arbitrary data specification
13/21
1 LCD TEST PATTERN OFF Pattern with built-in LCD controler display
2 LCD TEST PATTERN 1 OFF
3 LCD TEST PATTERN 2 OFF
4 LCD TEST PATTERN 3 OFF
5 LCD TEST PATTERN 4 OFF
Page Line Item Description Remarks (adjustment detail, etc.)
