LC-40/46LE812E, LC-40/46LX812E, LC-40/46/52LE822E, LC-40/46LU822E (1st Edition)
3 – 4
7. Adjustment process mode menu
The character string in brackets [ ] will appear as a page title in the adjustment process menu header.
Page Line Item Description Remarks (adjustment detail, etc.)
1/21
1 MAIN Version 1xxx (xxxxx) Main software version
2 BOOT Version xxxxxxx BOOT Version.
3 Monitor Version xxxxxxx Monitor software version
4 T-CON Version/LED CON Version xxxxxxxx/xxxx T-CON/H.264 Version
5 CPLD Version xxxxxxx CPLD Version.
7 CI+INFO/SECURE BOOT xxxxx/YES CI+ Key Information/SECURE BOOT
8 FRC-N Auto Script Version xxxxxxx
9 TCON Master/Slave Serial Version xxxxxxx
10 TOUCH SENSOR UCON VERSION xxxxxxx
11 LAMP ERROR 0 Number of termination due to lamp error.
12 MONITOR ERR CAUSE 1) xxxxxx 2) xxxxxx
3) xxxxxx 4) xxxxxx
Last error standby cause.
13 NORMAL STANDBY CAUSE 0 Situation that became standby at the end.
(Excluding the error)
14 ERROR STANDBY CAUSE 0 0 0 0 Error standby cause
2/21
1 INDUSTRY INIT Enter Initialization to factory settings execution.
2 INDUSTRY INIT (-Public) OFF Initialization to factory settings execution.
(Public mode is excluded)
3 PUBLIC MODE OFF Public mode ON/OFF setting
4 Center Acutime — Main operating hours.
5 RESET OFF Main operating hours reset.
6 Backlight Acutime — Backlight operating hours.
7 RESET OFF Backlight operating hours reset.
8 LAMP ERROR RESET OFF Lamp error reset.
9 ADJ PARAM SET Enter ADJ PARAM SET
10 VIC XPOS 0 X-coordinate setting for VIC READ
11 VIC YPOS 0 Y-coordinate setting for VIC READ
12 VIC SIGNAL TYPE MAIN Signal type setting for VIC READ
13 VIC READ OFF Picture level acquisition function
(Level appears in green on the upper right)
3/21
1 TUNER ADJ Enter TUNER auto adjustment execution
2 PAL+TUNER ADJ Enter PAL TUNER auto adjustment execution
3 TUNER ADJ (SMPTE) Enter TUNER auto adjustment execution (SMPTE)
4 PAL+TUNER ADJ (SMPTE) Enter PAL TUNER auto adjustment execution (SMPTE)
5 TUNER ADJ (SMPTE CH57) Enter TUNER auto adjustment execution (SMPTE CH57)
6 PAL+TUNER ADJ (SMPTE CH57) Enter PAL TUNER auto adjustment execution (SMPTE CH57)
7 TUNER CONTRAST A_GAIN 16 TUNER signal level adjustment
8 TUNER CONTRAST D_GAIN 2073 TUNER signal level adjustment
9 TUNER CONTRAST OFFSET 256 TUNER signal level adjustment
4/21
1 PAL ADJ Enter PAL adjustment
2 SECAM ADJ Enter SECAM adjustment
3 N358 ADJ Enter N358 adjustment
4 PAL CONTRAST A_GAIN 14 PAL contrast adjustment
5 PAL CONTRAST D_GAIN 2149 PAL contrast adjustment
6 PAL CONTRAST OFFSET 255 PAL contrast adjustment
7 SECAM CONTRAST A_GAIN 14 SECAM contrast adjustment
8 SECAM CONTRAST D_GAIN 2123 SECAM contrast adjustment
9 SECAM CONTRAST OFFSET 256 SECAM contrast adjustment
10 N358 CONTRAST A_GAIN 14 N358 contrast adjustment
11 N358 CONTRAST D_GAIN 2192 N358 contrast adjustment
12 N358 CONTRAST OFFSET 255 N358 contrast adjustment
