LC-40/46LE812E, LC-40/46LX812E, LC-40/46/52LE822E, LC-40/46LU822E (1st Edition)
vii
LC-40LE812E
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB UNIT
NOTE: (*1) Replace MAIN Unit (DKEYDF455FM06, DKEYDF455FM07) in case of IC8401 or IC3302 failure.
(*2) TOUCH SENSOR Unit (RUNTKA690WJQZ) reuse will be impossible, once it is stuck on front cabinet and
exfoliates.
Therefore, please exchange of a TOUCH SENSOR Unit in the case of front cabinet exchange.
OTHER UNIT
IC FOR EXCLUSIVE USE OF THE SERVICE
SERVICE JIGS
Ref No. Parts Code Description
N DKEYDF455FM06 MAIN Unit (LC-40/46LE812E, LC-40/46LX812E) (*1)
N DKEYDF455FM07 MAIN Unit (LC-40/46/52LE822E, LC-40/46LU822E) (*1)
N DUNTKF494FM02 R/C, LED Unit
N DUNTKF493FM03 ICON Unit
N DUNTKF493FM04 LOGO Unit (LC-40/46/52LE822E, LC-40/46LU822E)
N RUNTKA690WJQZ TOUCH SENSOR Unit (LC-40/46/52LE822E, LC-40/46LU822E) (*2)
N RUNTKA692WJQZ TOUCH SENSOR Unit (LC-40/46LE812E, LC-40/46LX812E)
N RUNTKA685WJQZ POWER/LED CONTROL Unit (LC-40LE812E/LX812E, LC-40LE822E/LU822E)
N RUNTKA686WJQZ POWER/LED CONTROL Unit (LC-46LE812E/LX812E, LC-46LE822E/LU822E)
N RUNTKA694WJQZ POWER/LED CONTROL Unit (LC-52LE822E)
N RUNTK4512TPZC LCD CONTROL Unit (LC-40LE812E/LX812E/LE822E/LU822E, LC-52LE822E)
N RUNTK4437TPZE LCD CONTROL Unit (LC-46LE812E/LX812E/LE822E/LU822E)
Ref No. Parts Code Description
N R1LK400D3LWF0Y 40" LCD Panel Module Unit (LC-40LE822E/LU822E)
N R1LK400D3LWF2Y 40" LCD Panel Module Unit (LC-40LE812E/LX812E)
N R1LK460D3LWA0Y 46" LCD Panel Module Unit (LC-46LE822E/LU822E)
N R1LK460D3LWA2Y 46" LCD Panel Module Unit (LC-46LE812E/LX812E)
N R1LK520D3LWA0Y 52" LCD Panel Module Unit (LC-52LE822E)
Ref No. Parts Code Description Q’ty
IC501 RH-iXD108WJQZS IC 24LC21AT-I/SN 1
IC2002 RH-iXC786WJNJQ IC R5F364A6NFB 1
Ref No. Parts Code Description Q’ty
N QCNW-G616WJQZ Main Unit to LCD Control Unit (LW) 1
N QCNW-G625WJQZ Main Unit to Power Unit (PL) 1
N QCNW-H184WJQZ Main Unit to Power Unit (PD) 1
N QCNW-H185WJQZ Main Unit to Power (LED Drive) Unit (LB) 1
N QCNW-K594WJQZ Main Unit to R/C, LED Unit (RA) 1
N QCNW-K595WJQZ Main Unit to Speaker (SP) 1
N QCNW-K596WJQZ Main Unit to Icon Unit (RL) (LC-40/46/52LE822E, LC-40/46LU822E) 1
N QCNW-K597WJQZ Main Unit to Woofer (SB) 1
