LC-40/46LE812E, LC-40/46LX812E, LC-40/46/52LE822E, LC-40/46LU822E (1st Edition)
1 – 1
LC-40LE812E
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item LCD COLOUR
TV (40 "/102 cm),
LC-40LE822E,
LC-40LU822E,
LC-40LE812E, LC-
40LX812E
LCD COLOUR
TV (46 "/117 cm),
LC-46LE822E,
LC-46LU822E,
LC-46LE812E, LC-
46LX812E
LCD COLOUR TV
(52 "/132 cm), LC-
52LE822E
LCD panel
102 cm (40 ")
X-Gen panel
117 cm (46 ")
X-Gen panel
132 cm (52 ")
X-Gen panel
Resolution 1,920 x 1,080 x 4 dots
Video colour system PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV function TV-standard Analogue CCIR (B/G, I, D/K, L/L')
Digital DVB-T (2K/8K OFDM), DVB-C, DVB-S/S2
Receiving
channel
VHF/UHF
IR A ch-E69 ch (Digital), E2-E69 ch, F2-F10 ch, I21-I69 ch, IR A-IR J ch
CATV
Hyper-band, S1-S41 ch
Satellite
950-2150 MHz*
3
TV-tuning system Auto Preset 999 ch (non-Nordic [DTV]), Auto Preset 9999 ch (Nordic [DTV]),
Auto Preset 99 ch (ATV), Auto Label, Auto Sort, Auto Preset 9999 ch (SAT)
STEREO/BILINGUAL NICAM/A2
Audio amplifier 10 W x 2/15 W x 1
Speaker (234 mm x 22 mm) x 2/Ø 110 mm
Terminals Antenna
UHF/VHF 75
Din type (analogue & digital), Satellite 75 F type (DVB-S/S2)
RS-232C D-Sub 9 pin male connector
EXT 1 SCART (AV input, Y/C input, RGB input, TV output)
EXT 2 RCA pin (AV input/AUDIO L/R)
EXT 3 15 pin mini D-sub
HDMI 1 (EXT 4) HDMI (ARC)
HDMI 2 (EXT 5) HDMI
HDMI 3 (EXT 6) HDMI
HDMI 4 (EXT 7) HDMI
USB USB
ETHERNET (10/100) Home network connector (only the 822 model series)
HDMI 2/EXT 3 AUDIO (L/R) Ø 3.5 mm jack*
1
DIGITAL AUDIO OUTPUT Optical S/PDIF digital audio output
C. I. (Common Interface) EN50221, R206001, CI Plus specification
OUTPUT/Headphones RCA pin (AUDIO R/L)/Ø 3.5 mm jack (audio output)
OSD language Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek,
Hungarian, Italian, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Russian,
Slovak, Slovene, Spanish, Swedish, Turkish, Ukrainian
Power requirement
AC 220-240 V, 50 Hz
Power consumption (method
IEC62087)
822 models 127 W (0.2 W standby*
2
) 147 W (0.2 W standby*
2
) 159 W (0.2 W standby*
2
)
812 models 127 W (0.2 W standby*
2
) 147 W (0.2 W standby*
2
)
Weight 822 models 19.5 kg (without stand),
23.5 kg (with stand)
24.5 kg (without stand),
30.0 kg (with stand)
30.0 kg (without stand),
35.0 kg (with stand)
812 models 16.0 kg (without stand),
19.5 kg (with stand)
20.5 kg (without stand),
26.0 kg (with stand)
Operating temperature
0°Cto+40°C
The HDMI 2 and EXT 3 terminals can both use the same audio input terminal.
Standby power consumption applies when the TV is set to not receive EPG data.
The satellite channel's frequency may vary according to satellites and antennas.
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be
some deviations from these values in individual units.
*1
*2
*3
