Sharp LC-40LE812E - Outline and Differences from Base Model Outline; Differences from Base Model; Lc-40 Le812 E;Lx812 E; Lc-46 Le812 E;Lx812 E

LC-40/46LE812E, LC-40/46LX812E, LC-40/46/52LE822E, LC-40/46LU822E (1st Edition)
i
LC-40LE812E
Service Manual
OUTLINE AND DIFFERENCES FROM BASE MODEL
OUTLINE
This Service Manual covers the differences from LC-40/46LE810E, LC-40/46LX810E and LC-40/46/52LE820E, LC-40/46LU820E.
For other technical information, refer to the LC-40/46LE810E, LC-40/46LX810E (No. S30E940LE810E) Service Manual and LC-40/46/52LE820E,
LC-40/46LU820E (No. S30F240LE820E) Service Manual.
DIFFERENCES FROM BASE MODEL (LC-40LE812E/LX812E)
DIFFERENCES FROM BASE MODEL (LC-46LE812E/LX812E)
Ref No. Description
LC-40LE810E/LX810E
(No. S30E940LE810E)
LC-40LE812E/LX812E
(No. S60G440LE812E)
Interchangeability Note
PRINTED WIRING BOARD ASSEMBLIES
N MAIN Unit DKEYDF455FM03 DKEYDF455FM06 Changed
N R/C, LED Unit DUNTKF494FM02 ← — No change
N ICON Unit DUNTKF493FM03 ← — No change
N TOUCH SENSOR Unit RUNTKA692WJQZ ← — No change
N POWER/LED CONTROL Unit RUNTKA685WJQZ ← — No change
N LCD CONTROL Unit RUNTK4512TPZC ← — No change
LCD PANEL
N 40" LCD Panel Module Unit R1LK400D3LWF2Y ← — No change
CABINET AND MECHANICAL PARTS
Please refer to a Parts Guide
SUPPLIED ACCESSORIES
Please refer to a Parts Guide
PACKING PARTS (NOT REPLACEMENT ITEM)
Please refer to a Parts Guide
Ref No. Description
LC-46LE810E/LX810E
(No. S30E940LE810E)
LC-46LE812E/LX812E
(No. S60G440LE812E)
Interchangeability Note
PRINTED WIRING BOARD ASSEMBLIES
N MAIN Unit DKEYDF455FM03 DKEYDF455FM06 Changed
N R/C, LED Unit DUNTKF494FM02 ← — No change
N ICON Unit DUNTKF493FM03 ← — No change
N TOUCH SENSOR Unit RUNTKA692WJQZ ← — No change
N POWER/LED CONTROL Unit RUNTKA686WJQZ ← — No change
N LCD CONTROL Unit RUNTK4437TPZE ← — No change
LCD PANEL
N 46" LCD Panel Module Unit R1LK460D3LWA2Y ← — No change
CABINET AND MECHANICAL PARTS
Please refer to a Parts Guide
SUPPLIED ACCESSORIES
Please refer to a Parts Guide
PACKING PARTS (NOT REPLACEMENT ITEM)
Please refer to a Parts Guide
Interchangeability
Completely interchangeableA:
=
NEWOLD
Interchangeable from
OLD to NEW
B:
ψ
NEWOLD
Interchangeable from
NEWtoOLD
C:
ψ
NEW OLD
Not interchangeableD:
X
OLDNEW
