LC-40/46LE812E, LC-40/46LX812E, LC-40/46/52LE822E, LC-40/46LU822E (1st Edition)
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[3] CABINET PARTS (LC-40LE812E/LX812E)
1 CCABAC527WJ11 N P Front Cabinet Ass'y (LC-40LE812E)
1 CCABAC527WJ13 N P Front Cabinet Ass'y (LC-40LX812E)
2 CCABBB698WJ14 N P Rear Cabinet Ass'y
2-1 Not available - N - Rear Cabinet
2-2 Not available - N - Terminal Label (Side)
2-3 Not available - N - Terminal Label (Bottom)
2-4 Not available - N - Himeron
2-5 Not available - - Spacer
2-6 Not available - N - Insulation Sheet
2-7 Not available - N - Himeron, x4
2-9 Not available - N - Himeron
2-10 Not available - N - Himeron
4 GCOVAD696WJ1A N P Stand Cover
5 GCOVAD699WJ1A N P AC Cord Cover
6 GCOVAD710WJSA N P Terminal Angle (Side)
7 GCOVAD711WJSA N P Terminal Angle (Bottom)
8 GCOVAD709WJ1A N P ECO Switch Cover
9 LANGKC719WJM1 N P Stand Angle
10 LANGKC743WJFW N P LCD Angle (Bottom-L)
11 LANGKC744WJFW N P LCD Angle (Bottom-R)
12 LANGKC745WJFW N P LCD Angle (Top-L)
13 LANGKC746WJFW N P LCD Angle (Top-R)
14 LANGKC775WJM1 N P VESA Angle, x2
15 LHLDKA011WJKZ AD J AC Cord Band
16 LHLDWA143WJKZ AC J Wire Holder, x5
17 LHLDWA294WJUZ AC J Wire Holder, x4
18 LHLDZA587WJKZ AC J Spacer, x5
19 LX-BZA170WJF9 AC J Screw (for VESA/Rear Cabinet Ass'y), x4
20 LX-BZA364WJF7 AB J Screw (for Woofer), x4
21 NSFTZA362WJFW N P Shaft (for PWB/Angle), x4
22 PCLiCA004WJKZ AC J Nylon Rivet, x2
23 PMLT-A636WJZZ N P Gasket
25 PZETKA548WJKZ N P Insulation Sheet (Power)
26 PZETKA556WJKZ N P
Insulation Sheet (ECO)
!
27 QACCKA052WJPZ N P AC Cord
28 QCNW-K976WJQZ AG N J Connecting Cord (PD)
29 QCNW-K977WJQZ AE N J Connecting Cord (PL)
30 QCNW-K551WJQZ N P Connecting Cord (RA)
31 QCNW-K978WJQZ AF N J Connecting Cord (LB)
32 QCNW-K553WJQZ N P Connecting Cord (SB)
33 QCNW-K554WJQZ N P Connecting Cord (SP)
!
35 QCNW-K556WJQZ N P Connecting Cord (AS)
36 QCNW-K576WJQZ N P Connecting Cord (LW)
37 QEARZ0057CEFW AB J Earth Spring
38 QEARZA186WJZZ N P Conductive Tape, x2
39 RSP-ZA474WJZZ N P Speaker (L/R), x2
40 RSP-ZA476WJZZ N P Speaker (Woofer)
41 TLABNC117WJZZ N P Model Label
44 XBPS730P06WS0 AA J Screw (for PWB/Angle/LCD/Cabinet), x39
45 XBPS730P10WS0 AA J Screw (for Panel Angle), x3
46 XBPS830P06WS0 AA J Screw (for Rear Cabinet Ass'y), x13
47 XBPS830P14WS0 N P Screw (for Rear Cabinet Ass'y)
48 XEBS840P10000 AF J Screw (for Speaker), x4
50 PSPAZC492WJKZ N P Spacer, x2
51 PSPAGA889WJKZ AE J Spacer, x2
52 PSPAGA891WJKZ AD J Spacer, x2
53 PZETKA563WJKZ N P Insulation Sheet (AC)
55 PCUSGA142WJKZ N P Rubber Bush, x2
56 PSPAZC494WJKZ N P Cooling Sheet
57 TLABZC453WJZZ N P Panel Label
58 PMLT-A637WJQZ N P Gasket
59 RCORFA023WJZZ AK J Core
60 TLABZC596WJZZ N P Label (LC-40LX812E)
