Sharp LC-40LE812E - Page 46

LC-40/46LE812E, LC-40/46LX812E, LC-40/46/52LE822E, LC-40/46LU822E (1st Edition)
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[4] CABINET PARTS (LC-46LE812E/LX812E)
1 CCABAC528WJ11 N P Front Cabinet Ass'y (LC-46LE812E)
1 CCABAC528WJ13 N P Front Cabinet Ass'y (LC-46LX812E)
2 CCABBB699WE14 N P Rear Cabinet Ass'y
2-1 Not available - N - Rear Cabinet
2-2 Not available - N - Terminal Label (Side)
2-3 Not available - N - Terminal Label (Bottom)
2-4 Not available - N - Himeron
2-5 Not available - - Spacer
2-6 Not available - N - Insulation Sheet
2-7 Not available - N - Himeron, x4
2-9 Not available - N - Himeron
2-10 Not available - N - Himeron
4 GCOVAD816WJ1A N P Stand Cover
5 GCOVAD699WJ1A N P AC Cord Cover
6 GCOVAD710WJSA N P Terminal Angle (Side)
7 GCOVAD711WJSA N P Terminal Angle (Bottom)
8 GCOVAD709WJ1A N P ECO Switch Cover
9 LANGKC720WJFW N P Stand Angle
10 LANGKC743WJFW N P LCD Angle (Bottom-L)
11 LANGKC744WJFW N P LCD Angle (Bottom-R)
12 LANGKC745WJFW N P LCD Angle (Top-L)
13 LANGKC746WJFW N P LCD Angle (Top-R)
14 LANGKC747WJFW N P LCD Angle (B-C-A)
15 LANGKC811WJFW N P LCD Angle (B-C-B)
16 LHLDKA011WJKZ AD J AC Cord Band
17 LHLDWA143WJKZ AC J Wire Holder, x3
19 LHLDWA294WJUZ AC J Wire Holder, x8
20 LHLDZA587WJKZ AC J Spacer, x5
21 LX-BZA170WJF9 AC J Screw (for VESA/Rear Cabinet Ass'y), x4
22 LX-BZA364WJF7 AB J Screw (for Woofer), x4
23 NSFTZA362WJFW N P Shaft (for PWB/Angle), x4
24 PCLiCA004WJKZ AC J Nylon Rivet, x2
25 PMLT-A636WJZZ N P Gasket
27 PZETKA541WJKZ N P
Insulation Sheet (Power)
28 PZETKA556WJKZ N P Insulation Sheet (ECO)
!
29 QACCKA052WJPZ N P AC Cord
30 QCNW-K976WJQZ AG N J Connecting Cord (PD)
31 QCNW-K977WJQZ AE N J Connecting Cord (PL)
32 QCNW-K978WJQZ AF N J Connecting Cord (LB)
!
33 QCNW-K556WJQZ N P Connecting Cord (AS)
34 QCNW-K572WJQZ N P Connecting Cord (RA)
35 QCNW-K559WJQZ AK N J Connecting Cord (SP)
37 QCNW-K570WJQZ AG N J Connecting Cord (SB)
38 QCNW-K577WJQZ AR N J Connecting Cord (LW)
39 QEARZ0057CEFW AB J Earth Spring
40 QEARZA186WJZZ N P Conductive Tape, x2
41 RSP-ZA474WJZZ N P Speaker (L/R), x2
42 RSP-ZA476WJZZ N P Speaker (Woofer)
43 TLABNC117WJZZ N P Model Label
46 XBPS730P06WS0 AA J Screw (for PWB/Angle/LCD/Cabinet), x37
47 XBPS730P10WS0 AA J Screw (for Panel Angle), x5
48 XBPS830P06WS0 AA J Screw (for Rear Cabinet Ass'y), x17
49 XBPS830P14WS0 N P Screw (for Rear Cabinet Ass'y)
50 XEBS840P10000 AF J Screw (for Speaker/Rear Cabinet Ass'y), x4
52 PSPAZC492WJKZ N P Spacer, x2
53 PSPAGA889WJKZ AE J Spacer, x2
54 PSPAGA891WJKZ AD J Spacer, x2
55 PSPAGA892WJKZ AD J Spacer
57 PZETKA563WJKZ N P Insulation Sheet (AC)
58 PCUSGA142WJKZ N P Rubber Bush
59 TLABZC453WJZZ N P Panel Label
60 PMLT-A637WJQZ N P Gasket
61 RCORFA020WJZZ AN J Core
62 RCORFA023WJZZ AK J Core
63 TLABZC596WJZZ N P Label (LC-46LX812E)
