LC-40/46LE830E, RU/831E, S

LC-40LE830E

Service Manual

OUTLINE

MAJOR SERVICE PARTS

PWB Unit

NOTE: (*1) Replace MAIN PWB Unit (DKEYDF733FM**) in case of IC8401 or IC3303 failure.

(*2) TOUCH SENSOR KEY Unit (RUNTKA869WJQZ) reuse will be impossible, once it is stuck on front cabinet and exfoliates.

OTHER Unit

IC For Exclusive Use Of The Service

Service Jigs

Ref No. Parts No. Description

N DKEYDF733FM51 MAIN Unit (LC-40/46LE830E, RU) (*1)

N DKEYDF733FM52 MAIN Unit (LC-40/46LE831E, S) (*1)

N DUNTKF494FM02 R/C, OPC Unit

N DUNTKF770FM51 ICON Unit

N RUNTKA869WJQZ TOUCH SENSOR KEY Unit (*2)

N RUNTKA819WJQZ IR TRANSMITTER Unit

N RUNTKA787WJQZ POWER Unit (LC-40LE830E, RU/831E, S)

N RUNTKA791WJQZ POWER Unit (LC-46LE830E, RU/831E, S)

N RUNTK4909TPZT LCD CONTROL Unit (LC-40LE830E, RU/831E, S)

N RUNTK4909TPZM LCD CONTROL Unit (LC-46LE830E, RU/831E, S)

Ref No. Parts No. Description

N R1LK400D3GW50Y 40" LCD Panel Module Unit (LK400D3GW50Y) (LC-40LE830E, RU/831E, S)

N R1LK460D3GW40Y 46" LCD Panel Module Unit (LK460D3GW40Y) (LC-46LE830E, RU/831E, S)

Ref No. Parts No. Description Q'ty

IC2001 RH-iXD241WJN2Q IC R5F21368CNFP (Monitor Microcomputer) 1

Ref No. Parts No. Description Q'ty

N QCNW-L795WJQZ Main Unit to Power Unit (PD) 1

N QCNW-L798WJQZ Main Unit to Touch Sensor/IR Transmitter Units (RC) 1

N QCNW-L796WJQZ Main Unit to ICON Unit (CI) 1

N QCNW-K595WJQZ Main Unit to Speaker (SP) 1

N QCNW-G405WJQZ Main Unit to LCD Control Unit (PL) 1

N QCNW-F676WJQZ Power Unit to LCD Control Unit (LW) 1

N QCNW-K597WJQZ Main Unit to Woofer (SB) 1
