40
Option
4:3 mode
The “WSS” signal has 4:3 auto-switching that allows you
to select between “Normal” and “Panorama”.
Go to “Menu” > “Setup” > “Option” > “4:3 mode”.
Item
Normal
Normal range keeping 4:3 or 16:9 aspect
ratio.
Panorama
Wide image without side bars.
WSS signal 4:3 screen
4:3 mode “Normal” 4:3 mode “Panorama”
Setting audio input
Option
Audio select
When using the PC terminal or HDMI2 terminal, you
must select which terminal uses the AUDIO IN jack for
analogue audio input.
Go to “Menu” > “Setup” > “Option” > “Terminal
setting” > “Audio select”.
When selecting “HDMI2” from the “INPUT” menu
Item
HDMI (Digital)
When connecting devices (including a
PC) with a HDMI cable to the HDMI2
terminal.
HDMI + Analog
When connecting devices (including a
PC) with a DVI/HDMI cable to the HDMI2
terminal and inputting analogue audio
signals from the AUDIO IN jack.
NOTE
• You must set this to “HDMI + Analog” when connecting
devices (including a PC) with an HDMI-certified cable to the
HDMI2 terminal. If “HDMI (Digital)” is set, there will be no
sound output.
When selecting “PC” from the “INPUT” menu
Item
Video
When connecting devices with AV cable
to the PC terminal, display images
without audio.
Video +Audio
When connecting a PC to the PC
terminal, and inputting analogue audio
signals from the AUDIO IN jack.
Skipping specified inputs
Option
Input skip
This setting allows you to skip the inputs on the input
source selection operation.
Go to “Menu” > “Setup” > “Option” > “Terminal
setting” > “Input skip”.
Useful viewing functions
