70
Appendix
Removing the stand
For wall mounting with the optional bracket (AN-37AG2
+ AN-37P30 or AN-52AG4) remove the stand.
Before setting TV on the wall
• Remove the connected cables (DVD, VCR, etc) from the
terminals.
• Before performing work, make sure to turn off the TV.
• Before performing work spread cushioning over the base area
to lay the TV on. This will prevent it from being damaged.
NOTE
• To attach the stand, perform the above steps in reverse order.
• As the TV is very heavy, be careful when moving it.
LC-52LE830X/LC-46LE830X/LC-40LE830X
1 Loosen the screw used to secure the stand cover
and remove the cover.
2 Remove the stand.
1 Unfasten the screws used to secure the stand
in place.
2 Detach the stand from the TV (hold the stand
so it will not drop from the edge of the base
area).
LC-40LE830X
LC-52/46LE830X
LC-60LE830X
1 Loosen the two screws used to secure the stand
cover.
2 Remove the stand.
1 Unfasten the four screws used to secure the
stand in place.
2 Remove the cover.
To Next Page
