Sharp LC-48CFE4042E User Manual

18
3.6 Wiring diagram of VGA, USB, AV, YPBR & COAX
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
D D
C C
B B
A A
FU1
MSMD110
5V_M
+
EU1
NC/100uF-16V-±20%-5×11-105
℃(寿命3KH)F
USB_5V
GND
1
2
3
4
GND-1
DM-1
DP-1
5V-1
5
6
GND GND
12
GND GND
7
8
GND-2
DM-2
DP-2
5V-2
9
10 11 12
AV5
USB
端子,USB Jack,H,Double,Black,flange,DIP,WLUS-074B,WLCO
GND
USB_5V
USB_5V
USB1_M
USB1_P
USB0_M
USB0_P
GND
USB1_DP
USB1_DM
GND
1
2
3
4
GND
DM
DP
5V
5
6
GND
GND
AV6
NC/USB-042M-002DP
USB_5V
USB1_P
USB1_M
USB0_DM
USB0_DP
RU1
NC/0ohm-0805-±5%-1/8W
RU2
0ohm-0402-±5%-1/16W
RU3
0ohm-0402-±5%-1/16W
RU4
0ohm-0402-±5%-1/16W
RU5
0ohm-0402-±5%-1/16W
CU1
10uF-0805-X5R-±20%-16V
YPbPr_Y
YPbPr_Pr
YPbPr_Pb
GND
GND
RI30
75ohm-0402-±5%-1/16W
RI19
75ohm-0402-±5%-1/16W
RI28
75ohm-0402-±5%-1/16W
GND CI23
0.047uF-0402-X7R-±10%-16V
CI21
0.047uF-0402-X7R-±10%-16V
CI22
0.047uF-0402-X7R-±10%-16V
PR2_IN
Y2_IN
PB2_IN
AV_R
AV_L
1
2
3
4
GND
AV-L/Pb
AV-R/Pr
AV-IN/Y
AV10
PJ-320A(Φ5.5mm)
AV_IN
GND
CI4
0.047uF-0402-X7R-±10%-16V
AV_CVBSIN0
RI12
75ohm-0402-±5%-1/16W
GND
RI13
10Kohm-0402-±5%-1/16W
RI15
10Kohm-0402-±5%-1/16W
GND
GND
CI6
0.1uF-0402-X5R-±20%-16V
CI8
0.1uF-0402-X5R-±20%-16V
CI7
NC/330pF-0402-NPO-±5%-50V
CI9
NC/330pF-0402-NPO-±5%-50V
RI14
12Kohm-0402-±5%-1/16W
RI16
12Kohm-0402-±5%-1/16W
RI18
NC/12Kohm-0402-±5%-1/16W
RI17
NC/12Kohm-0402-±5%-1/16W
GND
AV_R
AV_L
AV_IN
GND
SPDIF_OUT'
COAX
5V_M
RI47
0ohm-0402-±5%-1/16W
IR Transmitter
Vin
1
Vcc
2
GND
3
GND
4
GND
5
AV11
GQ-03-08C
COAX
GND
SPDIF_OUT
CI18
NC/0.1uF-0402-X5R-±20%-16V
GND
CI20
NC/NC/330pF-0402-NPO-±5%-50V
COAX
SPDIF_OUT'
CI10
NC/100pF-0402-NPO-±5%-50V
RI26
33ohm-0402-±5%-1/16W
RI24
33ohm-0402-±5%-1/16W
RI21
33ohm-0402-±5%-1/16W
AV_RIN
AV_LIN
RI11
厚膜电阻,RES,1/16W,150ohm,±1%,0402,SMD
AV_LIN/
AV_RIN/
AV_LIN/
AV_RIN/
1
2
3
4
GND
AV-L/Pb
AV-R/Pr
AV-IN/Y
AV13
PJ-320A(Φ5.5mm)
GND
YPbPr_Y
YPbPr_Pb
YPbPr_Pr
RI45
180ohm-0402-±5%-1/16W
R3
NC/120ohm-0402-±1%-1/16W
CI25
4700pF-0402-X7R-±10%-50V
CI26
1000pF-0402-X7R-±10%-50V
GND
AV_L
AV_R
CI24
NC/?
YPbPr_Y
YPbPr_Pb YPbPr_Pr
GND
GND
AV_R AV_L
AV_IN
1
2
3
4
GND
RIN
LIN
CN2 PJ-208B
GND
UART-TX
UART-RX
UART-TX
UART-RX
GND
1
2
3
4
CN5
连接插座,connect jack,4Pin,D2.0,D,L=2.8mm,DIP,LD
R23
100ohm-0402-±5%-1/16W
R28
100ohm-0402-±5%-1/16W
UART-RX/DDC
UART-TX/DDC
UART-TX/DDC1
TEST
UART-RX/DDC1
TEST
1 2
3 4
5 6
7 8
CN1
NC/2×4PIN-2.0-L-H-F-
镀金-LK
1
2
COAX
GND
3
GND
AV9
NC/RCA
端子,RCA Jack,AV1,H,Orange,CH5.5,Seal,DIP,AV38A-01S-5020,QS
CU2
10uF-0805-X5R-±20%-16V

Sharp LC-48CFE4042E Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	48 \
Display brightness	300 cd/m²
Display technology	LED
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	1000000:1
Display diagonal (metric)	121 cm
Motion interpolation technology	AMR (Active Motion Rate) 100
3D	No
Annual energy consumption	96 kWh
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2
Audio decoders	Dolby Digital, DTS TruSurround
RMS rated power	16 W
Number of speakers	2
On/off switch	-
Product color	Black
Panel mounting interface	400 x 400 mm
Audio formats supported	AAC, AC3, EAC3, LPCM, M4A, MP3
Image formats supported	BMP, JPEG, JPG, PNG
Video formats supported	ASF, AVI, FLV, H.264, H.265, HEVC, M2TS, M4V, MKV, MP4, MPG, RM, RMVB, SWF, TS, WMV
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	110 W
Power consumption (standby)	0.5 W
Power consumption (typical)	95 W
Power consumption (PowerSave)	66 W
Certification	CE, ErP, CB

Weight and Dimensions

Depth (with stand)	230 mm
Height (with stand)	691.8 mm
Weight (with stand)	14700 g
Depth (without stand)	91.9 mm
Width (without stand)	1097.6 mm
Height (without stand)	644.6 mm
Weight (without stand)	11700 g
