Sharp LC-52SB57U User Manual

LC-46SB57U/LC-52SB57U
15
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[4] DUNTKE264FM02 (R/C, LED Unit)
C102 VCKYTV1CF225ZY AB J Capacitor 2.2 16V Ceramic
C104 VCEASX1CN106MY AC J Capacitor 10 16V Electrolytic
C105 VCKYCY1HF103ZY AA J Capacitor 0.01 50V Ceramic
C107 VCEASY1CN107MY AC J Capacitor 100 16V Electrolytic
D101 RH-EXA092WJZZY AB J Diode UDZSFVTE-1712B
D103 RH-PX0421CEZZY AD J Diode CL-165HR/YG-D-T
D114 RH-PX0421CEZZY AD J Diode CL-165HR/YG-D-T
D115 RH-PX0421CEZZY AD J Diode CL-165HR/YG-D-T
IC101 VHiGA1S100W-1Y AE J IC GA1A1S100WP
P101 QPLGNA335WJZZY AD J Plug
Q102 VSKTC3875SG-1Y AB J Transistor
Q103 VSKTC3875SG-1Y AB J Transistor
Q104 VSKTC3875SG-1Y AB J Transistor
Q106 VSKTC3875SG-1Y AB J Transistor
Q107 VSKTC3875SG-1Y AB J Transistor
R101 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R104 VRS-CY1JF273JY AA J Resistor 27k 1/16W Metal Oxide
R105 VRS-CY1JF393JY AA J Resistor 39k 1/16W Metal Oxide
R108 VRS-CY1JF161JY AA J Resistor 160 1/16W Metal Oxide
R109 VRS-CY1JF821JY AA J Resistor 820 1/16W Metal Oxide
R117 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R121 VRS-CY1JF821JY AA J Resistor 820 1/16W Metal Oxide
R122 VRS-CY1JF161JY AA J Resistor 160 1/16W Metal Oxide
R123 VRS-CJ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R124 VRS-CJ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R135 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Receiver
SLD101 PSLDPA076WJFW AD J Shield Case Shield
[5] DUNTKE266FM02 (KEY Unit)
D151 RH-EX0646GEZZY AA J Diode MTZJT-7215B
D152 RH-EX0646GEZZY AA J Diode MTZJT-7215B
D155 RH-EX0646GEZZY AA J Diode MTZJT-7215B
P151 QPLGNA059WJZZ AC J Plug
R151 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch
S152 QSW-K0003AJZZ+ AB J Switch
S153 QSW-K0003AJZZ+ AB J Switch
S154 QSW-K0003AJZZ+ AB J Switch
S155 QSW-K0003AJZZ+ AB J Switch
S156 QSW-K0003AJZZ+ AB J Switch
S157 QSW-K0003AJZZ+ AB J Switch
