PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-46SB57U/LC-52SB57U
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
[3] DUNTKE833FM05 (MAIN Unit)
[4] DUNTKE264FM02 (R/C, LED Unit)
[5] DUNTKE266FM02 (KEY Unit)
[6] CABINET AND MECHANICAL
PARTS (LC-46SB57U)
[7] LCD MODULE Assembly
(LC-46SB57U)
[8] CABINET AND MECHANICAL
PARTS (LC-52SB57U)
[9] LCD MODULE Assembly
(LC-52SB57U)
[10] SUPPLIED ACCESSORIES
[11] PACKING PARTS (LC-46SB57U)
(NOT REPLACEMENT ITEM)
[12] PACKING PARTS (LC-52SB57U)
(NOT REPLACEMENT ITEM)
[13] SERVICE JIG
(USE FOR SERVICING)
CONTENTS
No. S49Y6LC46SB57
LCD COLOR TELEVISION
LC-46SB57U
LC-52SB57U
MODELS
