Sharp LC-52SB57U - Page 113

LC-46SB57U/LC-52SB57U
21
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[8] CABINET AND MECHANICAL PARTS (LC-52SB57U)
1 CCABAC123WJ01 BN X Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 HDECQA777WJ3A AX J LED Decoration
1-3 HPNLSA202WJKA AU N X SP Sheet
2 CCABBB540WJ01 BP N X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HiNDPC908WJSA AF X Terminal Label (Back)
3 R1LK520D3LW80Z EY X 52" LCD Panel Module Unit (LK520D3LW80Z2)
4 CCOVAC951WJ02 AK N X Side AV Cover Ass'y
4-1 Not Available - N - Side Terminal Cover
4-2 Not Available - N - Side Terminal Label
5 CCOVAC952WJ01 AK X KEY Button Cover Ass'y
5-1 Not Available - N - KEY Button Cover
5-2 Not Available - N - Control Button Label
6 CSLDMB612WJ01 AV X Control Shield Ass'y
6-1 PRDARA644WJFW AP X Control Radiator
6-2 Not Available - N - Control Shield
6-3 XBPS730P06WS0 AA J Screw (for Radiator), x6
7 GCOVAC576WJKZ X VESA Hole Cover, x4
8 GCOVAC954WJKA AM X Bottom Cover
9 HiNDPD313WJSA AD N X Model Label
10 LANGKB678WJN3 AV X Panel Support Angle, x2
11 LANGKC082WJFW AC X Main PWB Angle
12 LHLDWA133WJKZ AC J Wire Holder
13 LHLDWA151WJKZ AB J Wire Holder, x3
14 LHLDWA172WJKZ AD J Wire Holder
15 LHLDWA175WJUZ AC J Wire Holder, x3
16 LHLDWA176WJUZ AC J Wire Holder
17 LHLDZB144WJKZ AH X Corner Lug, x4
18 LHLDZB145WJKZ AD X Center Lug, x2
19 LHLDZB448WJ3Z AM N X Power PWB Holder
20 NSFTZA284WJFW AC J Hexagon Nut, x4
21 PMLT-A593WJZZ AC X Gasket (8x35x7T), x5
22 PMLT-A594WJZZ AD X
Gasket (8x50x7T), x5
23 PMLT-A597WJQZ AF X Gasket (Tuner)
24 PSLDMB560WJFW AR X Main PWB Shield
25 PSPAZB963WJKZ AD J Conductor (Jack), x2
26 PSPAZC234WJKZ AG X Spacer (D:23x23x3.5T)
27 PSPAZC235WJKZ AL X Spacer (A:35x15x4.5T)
28 PSPAZC236WJKZ AL X Spacer (B:35x23x3.5T)
29 QCNCMA275WJQZ AC J Connecting Cord (Model Selector), x2
30 QCNW-G163WJQZ AF X Connecting Cord (LA)
31 QCNW-G170WJQZ AE X Connecting Cord (PL)
32 QCNW-H493WJQZ AF X Connecting Cord (KM)
33 QCNW-H495WJPZ AL X Connecting Cord (SP)
34 QCNW-J139WJQZ AM X Connecting Cord (PD)
35 QCNW-J140WJQZ AK X Connecting Cord (LP)
36 QCNW-J141WJQZ AH X Connecting Cord (LB1)
37 QCNW-J142WJQZ AF X Connecting Cord (LB2)
38 QCNW-J147WJQZ AZ X Connecting Cord (LW)
39 QCNW-J591WJQZ AL N X Connecting Cord (RA)
40 RSP-ZA379WJZZ AQ X Speaker-L
41 RSP-ZA380WJZZ AQ X Speaker-R
42 XBPS830P06000 AA J Screw (for HDMI), x3
43 XBPS930P08JS0 AB J Screw
44 XEBS930P10000 AA J Screw (for S-Video, Bottom Cover), x2
45 XEBS940P16000 AB J Screw (for Cabinet), x18
46 XHPS830P06WS0 AA J Screw (for BL), x33
47 XHPS830P10WS0 AB J Screw (for Power PWB), x6
48 XHPS840P08WS0 AB J Screw (for Lug), x10
49 XiPSN20P04000 AA J Screw (for Side HDMI), x2
50 TLABK0023TAZZ AA J Label
51 TLABNB037WJZZ - - Serial No. Label (Back)
52 TLABNC391WJZZ - N - Serial No. Label (Side)
53 PSPAHB966WJZZ Spacer, x2
