LC-46SB57U/LC-52SB57U
5 – 10
36 1 LCD TEST PATTERN
2 TV TEST PATTERN 1
3 TV TEST PATTERN 2
37 1 KEY LOCK(1217)
2 KOUTEI AREA ALL CLEAR
3 A MODE AREA CLEAR
4 BACKUP AREA CLEAR
5 B MODE AREA CLEAR
6 EXECUTION
38 1 READ/WRITE
2 SLAVE ADDRESS
3 REGISTER ADDRESS UPPER
4 REGISTER ADDRESS LOWER
5 WRITE DATA UPPER
6 WRITE DATA LOWER
7 READ DATA UPPER
8 READ DATA LOWER
39 1 EEP SAVE Writing setting values to EEPROM
2 EEP RECOVER Reading setting values from EEPROM
3 STANDBY CAUSE RESET Reset stand by cause
4 SETTING FOR ADJ
40 1 BD UNIT FACTORY MENU
*1 Details of P1.9 (NORMAL STANDBY CAUSE)
2 No operation off in the cause of “no operation off”
3 No signal off in the cause of “no signal off”
4 PC power management mode 1 in the cause of “Standby mode MODE1”
5 PC power management mode 2 in the cause of “Standby mode MODE2”
6 Off timer in the cause of “SLEEP timer”
8 Command from RS232C in the cause of command by RS-232C
*2 Details of P1.10 (ERROR STANDBY CAUSE)
11 Prolonged unspecified-signal input in PC mode in the cause of continuous “out of range”, PC input mode
17 Temperature error in the cause of abnormal temperature
1A Monitor trouble detected in the cause of abnormal monitor mode
22 LCD controller Rom error in the cause of software abnormality of LCD controller
Page Line Item Description Remarks (adjustment detail, etc.)
