Sharp LC-60LE630U - MODIFIED PARTS; PRINTED WIRING BOARD AND LCD PANEL MODULES; CABINET, ACCESSORIES, AND SERVICE JIGS

LC-60LE630U/U(A), LC-70LE735U
ii
MODIFIED PARTS
Ref. No. Description
LC-60LE632U
LC-70LE732U
(S31O870LE732U)
LC-60LE630U/U(A)
LC-70LE735U
(S81S460LE630U)
Interchangeability Note
PRINTED WIRING BOARD ASSEMBLIES
N MAIN Unit (LC-60LE630U/U(A)) DKEYMF733FM17 DUNTKF905FM01 D Changed
N MAIN Unit (LC-70LE735U) DKEYMF733FM19 DKEYMF733FM26 D Changed
N R/C OPC Unit DUNTKF494FM01 ← — No changed
N ICON Unit (LC-60LE630U/U(A)) DUNTKF770FM02 ← — No changed
N ICON Unit (LC-70LE735U) DUNTKF770FM02 DUNTKF770FM03 D Changed
N KEY Unit (LC-60LE630U/U(A)) DUNTKF800FM50 ← — No changed
N KEY Unit (LC-70LE735U) DUNTKF800FM51 DUNTKF800FM50 D Changed
N WiFi Unit (LC-60LE630U/U(A)) RUNTKA810WJQZ — — Delete
N WiFi Unit (LC-70LE735U) RUNTKA810WJQZ ← — No changed
N 3D IR EMITTER Unit (LC-70LE735U) — RUNTKA819WJQZ D Add
N POWER/DRIVE Unit (LC-60LE630U/U(A)) RUNTKA847WJQZ ← — No changed
N POWER Unit (LC-70LE735U) RUNTKA857WJQZ RDENCA442WJQZ D Changed
N LCD Control Unit (LC-60LE630U/U(A)) DUNTKF778FM02 RUNTK4911TPZT D Changed
N LCD Control Unit (LC-70LE735U) DUNTKF778FM04 RUNTK4909TPYP D Changed
N LED DRIVER Unit (LC-70LE735U) — RUNTKA842WJZZ D Add
LCD PANEL MODULE
N
60" LCD Panel Module Unit (LK600D3GW70Z)
(LC-60LE630U)
R1LK600D3GW70Z ← — No changed
N
60" LCD Panel Module Unit (LK600D3GW7AZ)
(LC-60LE630U(A))
R1LK600D3GW70Z R1LK600D3GW7AZ D Changed
N
70" LCD Panel Module Unit (LK695D3GW20Z)
(LC-70LE735U)
R1LK695D3GW30Z R1LK695D3GW20Z D Changed
CABINET AND MECHANICAL PARTS
Please refer to a Parts Guide.
SUPPLIED ACCESSORIES/PACKING PARTS (NOT REPLACEMENT ITEM)
Please refer to a Parts Guide.
SERVICE JIG (USE FOR SERVICING)
Please refer to a Parts Guide.
Interchangeability
Completely interchangeableA:
=
NEWOLD
Interchangeable from
OLD to NEW
B:
NEWOLD
Interchangeable from
NEW to OLD
C:
NEW OLD
Not interchangeableD:
X
OLDNEW
