LC-60LE630U/U(A), LC-70LE735U
1 – 1
LC60LE630U
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS (LC-60LE630U/U(A))
Item Model: LC-60LE630U/LC-60LE630U(A)
LCD
panel
Size 60" Class (
60
1
/
32
" Diagonal)
Resolution 2,073,600 pixels (1,920 1,080)
TV
Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable
*1
(64/256 QAM)
1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Audio out 10W 2
Terminals
Rear
HDMI 1 HDMI in with HDCP, Audio in (ø 3.5 mm stereo minijack)
HDMI 2 HDMI in with HDCP
COMPONENT COMPONENT in
PC IN
ANALOG RGB (PC) in (15-pin mini D-sub female connector),
Audio in (ø 3.5 mm stereo minijack)
ANT/CABLE 75 Unbalance, F Type 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
AUDIO Audio in (ø 3.5 mm stereo minijack)
DIGITAL AUDIO OUTPUT
Optical Digital audio output 1 (PCM/Dolby Digital)
OUTPUT Audio out
Side
HDMI 3 HDMI in with HDCP
VIDEO AV in
SERVICE Software update
OSD language English/French/Spanish
Power Requirement AC 120 V, 60 Hz
Power Consumption 180 W (0.2 W Standby with AC 120 V)
Weight
TV + stand 71.7 lbs./32.5 kg
TV only 65.1 lbs./29.5 kg
Dimension
*2
(W H D)
TV + stand
54
29
/
64
34
19
/
64
13
1
/
8
inch
TV only 54
29
/
64
33 2
27
/
32
inch
Operating temperature
+32°F to +104°F (0°C to +40°C)
*1
Emergency alert messages via Cable are unreceivable.
*2
The dimensional drawings are shown on the Spanish operation manual.
The width include the operation buttons.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.
Cautions regarding use in high and low temperature environments
When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear slightly delayed.
This is not a malfunction, and the unit will recover when the temperature returns to normal.
Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near a
heater, as this may cause the cabinet to deform and the Liquid Crystal panel to malfunction.
Storage temperature: -4°F to +140°F (-20°C to +60°C)
