LC-60LE630U/U(A), LC-70LE735U
iii
MAJOR SERVICE PARTS
PWB Unit
(LC-60LE630U/U(A))
(LC-70LE735U)
NOTE: *1 Replace MAIN PWB Unit (DKEYMF733FM26) in case of IC8401, IC3303 or IC8455 failure.
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
Ref No. Parts No. Description
N DUNTKF905FM01 MAIN Unit
N DUNTKF494FM01 R/C, OPC Unit
N DUNTKF770FM02 ICON Unit
N DUNTKF800FM50 KEY Unit
N RUNTKA847WJQZ POWER Unit
N RUNTK4911TPZT LCD CONTROL Unit
Ref No. Parts No. Description
N DKEYMF733FM26 MAIN Unit (*1)
N DUNTKF494FM01 R/C, OPC Unit
N DUNTKF770FM03 ICON Unit
N DUNTKF800FM50 KEY Unit
N RUNTKA810WJQZ WiFi Unit
N RUNTKA819WJQZ 3D IR EMITTER Unit
N RDENCA442WJQZ POWER Unit
N RUNTK4909TPYP LCD CONTROL Unit
N RUNTKA842WJZZ LED DRIVER Unit
Ref No. Parts No. Description
N R1LK600D3GW70Z 60" LCD Panel Module Unit (LK600D3GW70Z) (LC-60LE630U)
N R1LK600D3GW7AZ 60" LCD Panel Module Unit (LK600D3GW7AZ) (LC-60LE630U(A))
N R1LK695D3GW20Z 70" LCD Panel Module Unit (LK695D3GW20Z) (LC-70LE735U)
Ref No. Parts No. Description Q'ty
IC508 RH-iXD397WJQZS IC S-24CS02AFJ-TB-G (RGB) (LC-60LE630U/U(A)) 1
IC1503 RH-iXD394WJQZS IC S-24CS02AFJ-TB-G (HDMI1) (LC-60LE630U/U(A)) 1
IC1504 RH-iXD396WJQZS IC S-24CS02AFJ-TB-G (HDMI3) (LC-60LE630U/U(A)) 1
IC1505 RH-iXD395WJQZS IC S-24CS02AFJ-TB-G (HDMI2) (LC-60LE630U/U(A)) 1
IC2001 RH-iXD241WJNBQ IC R5F21368CNFP (Monitor Microcomputer) (LC-70LE735U) 1
Ref No. Parts No. Description Q'ty
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit 2
N QCNW-F676WJQZ Connecting Cord L=1000mm 41pins, MAIN Unit to LCD Control Unit (LW) 1
N QCNW-M249WJQZ Connecting Cord L=1000mm, Main to LCD Control Unit (PD) (LC-60LE630U/U(A)) 1
N QCNW-L214WJQZ Connecting Cord L=1000mm, 64pins, LCD Control Unit to LCD Panel Unit (LC-70LE735U) 2
N QCNW-G405WJQZ Connecting Cord L=1000mm 4pins, POWER Unit to LCD Control Unit (PL) (LC-70LE735U) 1
N QCNW-L795WJQZ Connecting Cord L=1000mm 24pins, MAIN Unit to POWER Unit (PD) (LC-70LE735U) 1
N QCNW-L519WJQZ Connecting Cord L=1000mm 18pins, LED DRIVER Unit to POWER Unit (LA) (LC-70LE735U) 1
