Sharp LC-60LE635E Service Manual

LC-60LE635E/636E/638E (1st Edition)
6 – 3
No sound (during the reception of TV (DIGITAL) broadcasting)
Does not the sound go out though the picture has come out when DTV is received?
In the case of LE635E/636E series, refer to (A).
In the case of LE638E series, refer to (B).
(B)
(A)
Do IF signals output to pins [10, 11] of TUNER
(TU1102)?
NO Check the tuner and its peripheral circuits.
Replace as required.
YES
Do IF signals input to pins [35/IFPGA_INN, 36/
IFPGA_INP] of IC4402 (CI Cont & DTB-T/C Demod)?
NO Check the line between IC1102 and IC4402.
YES
Do TS signals output to pins [15/DEMOD_TS_DATA0,
16/DEMOD_TS_SYNC, 17/DEMOD_TS_VAL, 18/
DEMOD_TS_CLK] of IC4402?
NO Check IC4402 and its peripheral circuits.
YES
Do TS signals input to pins [U30/DEMOD_TSDATA0,
V30/DEMOD_TSSYNC, V29/DEMOD_TSVAL, U32/
DEMOD_TSCLK] of IC3303 (Digital AV decode & Main
CPU)?
NO Check the line between IC4402 and IC3303.
YES
Refer to “The sound is not emitted from the Speaker & Woofer though the picture has come out.”
Do TS signals output to pins [19/TS_TUOUT_CLK, 17/
TS_TUOUT_SYNC, 18/TS_TUOUT_VAL, 20~27/
TS_TUOUT_D0~7] of TUNER (TU1104)?
NO Check the tuner and its peripheral circuits.
Replace as required.
YES
Do TS signals input to pins [45/TS_TUOUT_CLK, 46/
TS_TUOUT_SYNC, 47/TS_TUOUT_VAL, 48, 51~57/
TS_TUOUT_D0~7] of IC4402 (CI Cont & DTB-T/C Demod)?
NO Check the line between TU1104 and IC4402.
YES
Do TS signals output to pins [15/DEMOD_TS_DATA0, 16/
DEMOD_TS_SYNC, 17/DEMOD_TS_VAL, 18/
DEMOD_TS_CLK] of IC4402?
NO Check IC4402 and its peripheral circuits.
YES
Do TS signals input to pins [U30/DEMOD_TSDATA0, V30/
DEMOD_TSSYNC, V29/DEMOD_TSVAL, U32/
DEMOD_TSCLK] of IC3303 (Digital AV decode & Main CPU)?
NO Check the line between IC4402 and IC3303.
YES
Refer to “The sound is not emitted from the Speaker & Woofer though the picture has come out.”
