Sharp LC-60LE635E Service Manual

LC-60LE635E/636E/638E (1st Edition)
4 – 2
2. Removing of Speaker-L/R.
1. Remove the 2 lock screws and the 1 lock screw detach the Bottom Cover .
2. Remove the 14 lock screws and detach the Fixing Metal Angle .
3. Disconnect SP wire.
4. Detach the Speaker-L , Speaker-R .
[SP]
[SP]
5Speaker-L6Speaker-R
3
1
4
Fixing Metal Angle
2 Bottom Cover
MAIN Unit
7
