Sharp LC-60LE635E Service Manual

LC-60LE635E/636E/638E (1st Edition)
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKF733FM55 N P MAIN Unit(LC-60LE635E)
N DUNTKF733FM56 N P MAIN Unit(LC-60LE636E)
N DUNTKF733FM57 N P MAIN Unit(LC-60LE638E)
N DUNTKF494FM02 P R/C OPC Unit
N DUNTKF770FM53 N P ICON Unit
N DUNTKF800FM52 N P KEY Unit
N RUNTK4910TPZT N P LCD Control Unit
!
N RUNTKA847WJN1 N P Power Unit
[2] LCD PANEL MODULE UNIT
N R1LK600D3GW7CH N P 60" LCD PANEL (LK600D3GW7CH)
[3] DUNTKF733FM55/56/57 (MAIN Unit)
C1101 VCKYCZ1EB822KY AA J Capacitor 8200p 25V Ceramic (excepe LC-60LE636E)
C1102 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (excepe LC-60LE636E)
C1104 RC-KZA621WJQZY AA J Capacitor (excepe LC-60LE636E)
C1106 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic (excepe LC-60LE636E)
C1107 VCEASH1EN686MY AD J Capacitor 68 25V Electrolytic (excepe LC-60LE636
C1108 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic (excepe LC-60LE636E)
C1111 VCEASH1EN686MY AD J Capacitor 68 25V Electrolytic (excepe LC-60LE636
C1112 RC-KZA237WJZZY AB J Capacitor (excepe LC-60LE636E)
C1113 RC-KZA709WJQZY AA J Capacitor (excepe LC-60LE636E)
C1114 RC-KZA621WJQZY AA J Capacitor (excepe LC-60LE636E)
C1115 RC-KZA383WJZZY AC J Capacitor (excepe LC-60LE636E)
C1116 RC-KZA709WJQZY AA J Capacitor (excepe LC-60LE636E)
C1117 RC-KZA709WJQZY AA J Capacitor (excepe LC-60LE636E)
C1118 RC-KZA237WJZZY AB J Capacitor (for LC-60LE636E)
C1119 RC-KZA383WJZZY AC J Capacitor (excepe LC-60LE636E)
C1120 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (excepe LC-60LE636E)
C1123 VCKYCZ1AB473KY AB J Capacitor 0.047 10V Ceramic (excepe LC-60LE636E)
C1125 VCKYCZ1AB473KY AB J Capacitor 0.047 10V Ceramic (excepe LC-60LE636E)
C1130 RC-KZA237WJZZY AB J Capacitor (excepe LC-60LE636E)
C1174 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic (for LC-60LE636E)
C1175 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic (for LC-60LE636E)
C1178 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (excepe LC-60LE636E)
C1179 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (for LC-60LE636E)
C1180 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (for LC-60LE636E)
C1181 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (excepe LC-60LE636E)
C1182 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (excepe LC-60LE636E)
C1183 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (excepe LC-60LE636E)
C1184 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (excepe LC-60LE636E)
C1188 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic (excepe LC-60LE636E)
C1189 VCKYCY1EB104KY AB J Capacitor 0.1 25V Ceramic (excepe LC-60LE636E)
C1190 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (excepe LC-60LE636E)
C1191 RC-KZA531WJQZY AA J Capacitor (for LC-60LE636E)
C1192 RC-KZA531WJQZY AA J Capacitor (for LC-60LE636E)
C1193 VCKYCZ1EB103KY AA J
Capacitor 0.01 25V Ceramic (for LC-60LE636E)
C2002 V
CKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C2005 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C2603 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C2604 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C2605 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C2606 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C2607 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C2608 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C2609 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C2610 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C3519 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C3520 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C3521 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C3522 RC-KZA237WJZZY AB J Capacitor
C3523 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C3524 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C3525 RC-KZA237WJZZY AB J Capacitor
C3526 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C3527 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C4461 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (excepe LC-60LE636E)
C4462 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic (excepe LC-60LE636E)
D1101 VHDRB156L40-1Y AC J Diode RB156L-40TE25 (excepe LC-60LE636E)
D1102 VHD1SR154++-1Y AC J Diode 1SR154-400TE25 (excepe LC-60LE636E)
D1103 VHDRB156L40-1Y AC J Diode RB156L-40TE25 (excepe LC-60LE636E)
D1104 VHDRB156L40-1Y AC J Diode RB156L-40TE25 (excepe LC-60LE636E)
D1105 VHDRB156L40-1Y AC J Diode RB156L-40TE25 (excepe LC-60LE636E)
FB1101 RBLN-A192WJZZY AA J Ferrite Core (excepe LC-60LE636E)
FB1104 RBLN-A192WJZZY AA J Ferrite Core (excepe LC-60LE636E)
FB2023 RBLN-A192WJZZY AA J Ferrite Core
FB2024 RBLN-A192WJZZY AA J Ferrite Core
FB2601 RBLN-A042WJZZY AB J Ferrite Core
FB2602 RBLN-A042WJZZY AB J Ferrite Core
FB2603 RBLN-A042WJZZY AB J Ferrite Core
FB2604 RBLN-A074WJZZY AA J Ferrit
e Core
FB2605 RBLN-A042WJZZY AB J Ferrite Core
FB2606 RBLN-A074WJZZY AA J Ferrite Core
FB2607 RBLN-A074WJZZY AA J Ferrite Core
FB2608 RBLN-A042WJZZY AB J Ferrite Core
