Sharp LC-60LE651 MK2 - Power Unit and Main Unit Removal; Chassis Bracket and Control Holder Removal

24
LC-60LE651 MK2
LC-60LE652 MK2
1. Removing of major Parts 60” (Continued)
1.4. Remove the 4 lock screws h and detach the POWER unit.
1.5. Remove the 4 lock screws i and detach the MAIN unit.
1.6. Remove the 1 lock screw j and detach the chassis BRACKET.
1.7. Remove the SPEAKER-L k and SPEAKER-R l.
SPEAKER -R
SPEAKER -L
9
10
MAIN
unit
7
chassis
BRACKET
6
POWER
unit
8
