Sharp LC-60LE651 MK2 - Key Unit and Diffuser Removal

25
LC-60LE651 MK2
LC-60LE652 MK2
1. Removing of major Parts 60” (Continued)
1.8. Remove the 16 lock screws ⑪ and detach the stand BRACKET.
1.9. Remove the 2 lock screws ⑫ and detach the control button HOLDER.
1.10. Detach the KEY unit ⑬ and the pyramid lighting DIFFUSER ⑭.
stand
BRACKET
11
piramid
lighting
DIFFUSER
KEY
unit
control
button
HOLDER
12
13
14
