Sharp LC-60LE745U - Removing Bottom Cover and KEY Unit (70 Models)

LC-60/70LE745U,C7450U,LE845U,C8470U,LE847U (1st Edition)
4 – 9
2. Removing of Bottom Cover and KEY Unit.
1. Remove the 1 lock screw and detach the KEY Unit Ass’y .
2. Disconnect the KM wire.
3. Detach the KEY Unit from Key Button .
4. Detach the 2 Bottom Covers .
[KM]
5 Bottom Cover
1
4 Key Button
3 KEY Unit
2
KEY Unit
Ass'y
