Sharp LC-60LE757U Service Manual

LC-60/70LE650U/C6500U/LE657U,LC-60/70LE755U/LE757U/LE857U/C7500U
15
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R3843 VRS-CZ1JF472JY AA J 4.7k 1/16W Metal Oxide
R3844 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R3846 VRS-CZ1JF100JY AA J 10 1/16W Metal Oxide
R3849 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R3850 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R3851 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R3856 VRS-CZ1JF103JY AA J 10k 1/16W Metal Oxide
R3858 VRS-CZ1JF103JY AA J 10k 1/16W Metal Oxide
R9401 VRS-CZ1JF751FY AA J 750 1/16W Metal Oxide
R9402 VRS-CZ1JF751FY AA J 750 1/16W Metal Oxide
R9403 VRS-CZ1JF751FY AA J 750 1/16W Metal Oxide
R9404 VRS-CZ1JF751FY AA J 750 1/16W Metal Oxide
R9405 VRS-CZ1JF750FY AA J 75 1/16W Metal Oxide
R9406 VRS-CZ1JF750FY AA J 75 1/16W Metal Oxide
R9407 VRS-CZ1JF750FY AA J 75 1/16W Metal Oxide
R9408 VRS-CZ1JF750FY AA J 75 1/16W Metal Oxide
R9409 VRS-CZ1JF103JY AA J 10k 1/16W Metal Oxide
R9410 VRS-CZ1JF103JY AA J 10k 1/16W Metal Oxide
R9411 VRS-CZ1JF103JY AA J 10k 1/16W Metal Oxide
R9416 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R9417 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R9420 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R9421 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R9425 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R9426 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R9429 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R9430 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R9501 VRS-CZ1JF104JY AA J 100k 1/16W Metal Oxide
R9502 VRS-CZ1JF473JY AA J 47k 1/16W Metal Oxide
R9504 VRS-CZ1JF000JY AA J 0 1/16W Metal Oxide
R9505 VRS-CZ1JF393JY AA J 39k 1/16W Metal Oxide
R9506 VRS-CZ1JF273JY AA J 27k 1/16W Metal Oxide
R9601 VRS-CZ1JF103FY AB J 10k 1/16W Metal Oxide
R9602 VRS-CZ1JF473JY AA J
47k 1/16W Metal Oxide
R9
603 VRS-CZ1JF222JY AA J 2.2k 1/16W Metal Oxide
R9604 VRS-CZ1JF103FY AB J 10k 1/16W Metal Oxide
R9605 VRS-CZ1JF103FY AB J 10k 1/16W Metal Oxide
R9606 VRS-CZ1JF473JY AA J 47k 1/16W Metal Oxide
R9607 VRS-CZ1JF103FY AB J 10k 1/16W Metal Oxide
R9608 VRS-CZ1JF100JY AA J 10 1/16W Metal Oxide
R9609 VRS-CZ1JF472JY AA J 4.7k 1/16W Metal Oxide
R9610 VRS-CZ1JF562JY AA J 5.6k 1/16W Metal Oxide
R9611 VRS-CZ1JF103FY AB J 10k 1/16W Metal Oxide
R9612 VRS-CZ1JF100JY AA J 10 1/16W Metal Oxide
R9613 VRS-CZ1JF103FY AB J 10k 1/16W Metal Oxide
R9615 VRS-CZ1JF562JY AA J 5.6k 1/16W Metal Oxide
R9616 VRS-CZ1JF223FY AA J 22k 1/16W Metal Oxide
R9617 VRS-CZ1JF223FY AA J 22k 1/16W Metal Oxide
R9618 VRS-CZ1JF223FY AA J 22k 1/16W Metal Oxide
R9619 VRS-CZ1JF100JY AA J 10 1/16W Metal Oxide
R9620 VRS-CZ1JF473JY AA J 47k 1/16W Metal Oxide
R9621 VRS-CZ1JF683FY AA J 68k 1/16W Metal Oxide
R9622 VRS-CZ1JF562JY AA J 5.6k 1/16W Metal Oxide
R9623 VRS-CZ1JF100JY AA J 10 1/16W Metal Oxide
R9624 VRS-CZ1JF100JY AA J 10 1/16W Metal Oxide
R9626 VRS-CZ1JF473JY AA J 47k 1/16W Metal Oxide
R9627 VRS-CZ1JF472JY AA J 4.7k 1/16W Metal Oxide
R9628 VRS-CZ1JF223FY AA J 22k 1/16W Metal Oxide
R9629 VRS-CZ1JF100JY AA J 10 1/16W Metal Oxide
R9630 VRS-CZ1JF683FY AA J 68k 1/16W Metal Oxide
R9631 VRS-CZ1JF103JY AA J 10k 1/16W Metal Oxide
R9632 VRS-CZ1JF102JY AA J 1.0k 1/16W Metal Oxide
R9633 VRS-CZ1JF473FY AA J 47k 1/16W Metal Oxide
R9637 VRS-CZ1JF102JY AA J 1.0k 1/16W Metal Oxide
R9638 VRS-CZ1JF103JY AA J 10k 1/16W Metal Oxide
SC501 QSOCNB116WJQZ AC X Socket
SC504 QSOCNB115WJQZ AC X Socket
SC1501 QSOCZA321WJQZY AD J S
ocket
SC1502 QSOCZA321WJQZY AD J Socket
SC1503 QSOCZA321WJQZY AD J Socket
SC1504 QSOCZA321WJQZY AD J Socket
SC3801 QCNCWA671WJQZY AH J Connector
T9401 RTRNZA143WJQZY AF J Transformer
TH2001 VHHM1103J15-1Y AB J THERMISTOR
TU1104 RTUDAA083WJQZ AN X Tuner
VA501 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA502 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA511 RH-VXA238WJQZY AA J CDS2C05HDMI2
VA512 RH-VXA238WJQZY AA J CDS2C05HDMI2
VA513 RH-VXA238WJQZY AA J CDS2C05HDMI2
VA514 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA515 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA521 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA522 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA523 RH-VXA238WJQZY AA J CDS2C05HDMI2
[2] DKEYMF953FM06 (MAIN Unit)
