Sharp LC-60LE757U Service Manual

LC-60/70LE650U/C6500U/LE657U,LC-60/70LE755U/LE757U/LE857U/C7500U
16
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
VA524 RH-VXA238WJQZY AA J CDS2C05HDMI2
VA525 RH-VXA238WJQZY AA J CDS2C05HDMI2
VA526 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA527 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA528 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA529 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA530 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA531 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA532 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA533 RH-VXA236WJZZY AA J SDV1005H180C120NPT
VA9501 RH-VXA238WJQZY AA J CDS2C05HDMI2
VA9502 RH-VXA238WJQZY AA J CDS2C05HDMI2
VA9503 RH-VXA238WJQZY AA J CDS2C05HDMI2
VA9504 RH-VXA238WJQZY AA J CDS2C05HDMI2
X1701 RCRSCA276WJQZY AC J Crystal
X3301 RCRSCA278WJQZY AB X Crystal
[3] DUNTKF975FM20 (LCD CONTROL Unit)
C4801 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C4823 RC-AZA074WJZZY AE J Capacitor
C4824 VCKYCY1EB104KY AB J 0.10 25V Ceramic
C4825 VCKYCY1EB104KY AB J 0.10 25V Ceramic
C4829 RC-AZA074WJZZY AE J Capacitor
C4905 RC-KZA176WJZZY AC J Capacitor
C4906 RC-KZA176WJZZY AC J Capacitor
C4907 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C4908 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C4909 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C4910 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C4911 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C4912 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C4913 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C4914 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C4915 RC-KZA116WJZZY AC J Capacitor
C4916 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4917 RC-KZA116WJZZY AC J Capacitor
C4918 RC-KZA116WJZZY AC J Capacitor
C4919 RC-KZA116WJZZY AC J Capacitor
C4920 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4921 RC-KZA116WJZZY AC J Capacitor
C4922 RC-KZA116WJZZY AC J Capacitor
C4923 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4924 RC-KZA116WJZZY AC J Capacitor
C4925 RC-KZA116WJZZY AC J Capacitor
C4926 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4927 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4928 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4929 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4930 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4931 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4932 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4933 VCKYCZ1EB103KY AA J
0.010 25V Ceramic
C4934 V
CKYCZ1EB103KY AA J 0.010 25V Ceramic
C4935 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4936 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4937 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4938 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4939 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4940 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4941 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4945 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C4946 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C5103 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5104 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5105 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5106 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5107 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5108 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5109 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5110 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5111 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5801 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C5802 RC-KZA510WJPZY AB J Capacitor
C5803 RC-KZA510WJPZY AB J Capacitor
C5804 VCKYCZ1HB472KY AA J 4700p 50V Ceramic
C5805 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C5806 VCKYCZ1HB472KY AA J 4700p 50V Ceramic
C5807 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5808 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5809 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5810 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5812 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5813 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5814 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C5816 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
[2] DKEYMF953FM06 (MAIN Unit)
