LC-65D64U
1 – 1
LC-65D64U
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item Model: LC-65D64U
LCD panel
65" Advanced Super View & BLACK TFT LCD
(Screen size 64
33
/
64
measured diagonally)
Number of dots 6,220,800 dots (1920 1080 3 dots)
TV
Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable
*1
(64/256 QAM)
1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Audio out 15W 2
Terminals
Rear
INPUT 1 AV in, COMPONENT in
INPUT 2 AV in, S-VIDEO in
INPUT 5 HDMI in with HDCP
INPUT 6 Audio in, HDMI in with HDCP
INPUT 7 15-pin mini D-sub female connector, Audio in (Ø 3.5 mm jack)
ANTENNA 75 Unbalance, F Type 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
DIGITAL AUDIO OUTPUT
Optical Digital audio output 1 (PCM/Dolby Digital)
OUTPUT Audio out
RS-232C 9-pin D-sub male connector
Side
INPUT 3 AV in, COMPONENT in
INPUT 4 HDMI in with HDCP
USB Software update
OSD language English/French/Spanish
Power Requirement
AC 120 V, 60 Hz (FOR NORTH AMERICA)
AC 110-240 V, 50/60 Hz (FOR OTHERS)
Power Consumption 525 W (0.35 W Standby with AC 120V)
Weight
TV + stand 121.3 lbs./55.0 kg
TV only 110.3 lbs./50.0 kg
Dimension
*2
(W H D)
TV + stand 60
11
/
64
40 15
7
/
8
inch
TV only 60
11
/
64
37
11
/
64
3
7
/
8
inch
Operating temperature 32°F to 104°F (0°C to 40°C)
*1
Emergency alert messages via Cable are unreceivable.
*2
The dimensional drawings are shown on the inside back cover.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.
++ +
"
