Sharp LC-65LE645U - Spare Parts List

CONFIDENTIAL – DO NOT COPY
Page 13-1
File No. SG-0000313
Chapter 13 Spare Parts List
PART NO DESCRIPTION LOC QTY
REMARK
(Child
P/N Seq)
9LE 018467510083 POLYSWITCH 0.75A 8V SMD (1206L075THYR) HF FU5 1 M
9LE 018467510084
POLYSWITCH 0.75A 8V SMD (KMC3S075RY006)
HF
FU5 1 S
9LE 028027000213
X'TAL 27MHZ HC-49S 30PPM 20PF 18ohm + W/O
PAD -20~85'C HF
Y1,YM2 2
9LE 045120000406 WAFER 2.0mm 4P 180' DIP KINK (M24264) HF J1,JI3 2 M
9LE 045120030403 WAFER 2.00mm 4P 180' KINK (A2001WV2-4P) L-F J1,JI3 2 S
9LE 045112500486 WAFER 1.25mm 4P 180' SMD (MS24014) L-F JM2 1
9LE 045120000606 WAFER 2.0mm 6P 180' DIP KINK (M24266) HF J13 1
9LE 045120030603 WAFER 2.00mm 6P 180' KINK (A2001WV2-6P) L-F J13 1
9LE 045120001066 WAFER 2.0mm 10P 90' DIP KINK (M242610R) HF JP1 1 M
9LE 045120031063
WAFER 2.00mm 10P 90' KINK (A2001WR2-10P)
L-F
JP1 1 S
9LE 045125000446 WAFER 2.5mm 4P 90' DIP KINK (M241854R) L-F JA1 1 M
9LE 045125000443 WAFER 2.50mm 4P 90' KINK (A2501WR2-4P) L-F JA1 1 S
9LE 045125000449 WAFER 2.50mm 4P 90' KINK (A2501WR-04P1) L-F JA1 1 S
9LE 030480000240
RJ45 CONN. 90' Without/LED (5450-025-1G3-A9)
LF
JN1 1
9LE 030062000051 USB CONN. A TYPE 90' (UB1112C-4K5-4F) L-F PU3 1 M
9LE 030062000130 USB CONN. A TYPE 90' (3AL04S-305-ZC) L-F PU3 1 S
9LE 030062000200 USB CONN. A TYPE 90' (184-0420112-AT) LF PU3 1 S
9LE 030064000070 OPTO CONN. Transmitter (JST1221) L-F PA1 1 M
9LE 030064000140 OPTO CONN. 90' Transmitter 16MB (GQ48T-01) LF PA1 1 S
9LE 030290200039 RCA JACK 1ROW 2I/O 90' (W-R) (RCA215D-01) LF PA2 1 M
9LE 030290200270
RCA JACK 1ROW 2I/O 90' (W-R)
(WT-04066V2B-06H) L-F
PA2 1 S
9LE 030290500049
RCA JACK 1ROW 5IO 90'(GBRWR)(RCA546D-01)
LF
PV1 1 M
9LE 030290500071
RCA JACK 1R 5IO
90'(GBRWR)(WTJ-032-55V2B-01A) LF
PV1 1 S
