Sharp LC-65LE645U - Page 76

Level
Child
P/N Seq
Child P/N Specification UIT Supply Type UOM Qty Circuit Number
4 1 9LE 170119821010 GUIDE PANEL_T(PC+GF10 FR/T52013)(EM65FTR) G Supplier EA 1
4 1 9LE 194720003500 RUBBER PAD(SILICON 94V-0 10u/630*3*0.4t)(DEEP GRAY) G Supplier EA 2
4 1 9LE 194720003530 RUBBER PAD(SILICON 94V-0 10u/642*4*1.0t)(DEEP GRAY) G Supplier EA 2
3 1 9LE 180119822030 GUIDE PANEL_B(PC+GF10 FR/T52013)(EM65FTR)(INX)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119822000 GUIDE PANEL_B(EM65FTR) G Supplier EA 1
4 1 9LE 170119822030 GUIDE PANEL_B(PC+GF10 FR/T52013)(EM65FTR)(INX) G Supplier EA 1
4 21 9LE 194720003500 RUBBER PAD(SILICON 94V-0 10u/630*3*0.4t)(DEEP GRAY) G Supplier EA 2
4 11 9LE 194720003530 RUBBER PAD(SILICON 94V-0 10u/642*4*1.0t)(DEEP GRAY) G Supplier EA 2
3 1 9LE 180119823030 GUIDE PANEL_L(PC+GF10 FR/T52013)(EM65FTR)(INX)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119823000 GUIDE PANEL_L(EM65FTR) G Supplier EA 1
4 1 9LE 170119823030 GUIDE PANEL_L(PC+GF10 FR/T52013)(EM65FTR)(INX) G Supplier EA 1
4 1 9LE 194715009660 FOAM PAD(80.0*3.0*0.4t)(BLK) G Supplier EA 2
4 1 9LE 194715009730 FOAM PAD(36*6.0*0.3t)(BLK) G Supplier EA 6
4 1 9LE 194720003121 RUBBER PAD(SILICON 94V-0 10u/815*3*1.0t)(DEEP GRAY) G Supplier EA 1
4 1 9LE 194720003141 RUBBER PAD(SILICON 94V-0 10u/72*3*1.0t)(DEEP GRAY) G Supplier EA 2
4 11 9LE 194720003510 RUBBER PAD(SILICON 94V-0 10u/815*3*0.4t)(DEEP GRAY) G Supplier EA 1
3 1 9LE 180119824030 GUIDE PANEL_R(PC+GF10 FR/T52013)(EM65FTR)(INX)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119824000 GUIDE PANEL_R(EM65FTR) G Supplier EA 1
4 1 9LE 170119824030 GUIDE PANEL_R(PC+GF10 FR/T52013)(EM65FTR)(INX) G Supplier EA 1
4 1 9LE 194715009660 FOAM PAD(80.0*3.0*0.4t)(BLK) G Supplier EA 2
4 1 9LE 194715009730 FOAM PAD(36*6.0*0.3t)(BLK) G Supplier EA 6
4 1 9LE 194720003121 RUBBER PAD(SILICON 94V-0 10u/815*3*1.0t)(DEEP GRAY) G Supplier EA 1
4 1 9LE 194720003141 RUBBER PAD(SILICON 94V-0 10u/72*3*1.0t)(DEEP GRAY) G Supplier EA 2
4 11 9LE 194720003510 RUBBER PAD(SILICON 94V-0 10u/815*3*0.4t)(DEEP GRAY) G Supplier EA 1
3 1 9LE 194712000401 ACETATE CLOTH TAPE 20*45mm G Assembly Pull EA 21
3 1 9LE 194712009300 PET TAPE(3M SUPER10/30*25*0.06t)(TRANSPARENT)(LC-65LE643U) G Assembly Pull EA 5
3 1 9LE 194724001610 MYLAR(PC/27.0*12.0*0.125t)(BLACK) G Assembly Pull EA 12
3 1 9LE 36650142030C BLACKLIGHT ASS'Y LC-65LE645U (INX_V650HP1-PS6) P Phantom EA 1
4 1 9LE 0981010221BR 65 inch L/B module 8PCS- A(Nitride 3043_INX_V650HP1-PS6) G Assembly Pull EA 8
4 1 9LE 0981010221BS 65 inch L/B module 8PCS- B(Nitride 3043_INX_V650HP1-PS6) G Assembly Pull EA 4
4 1 9LE 0981010221BT 65 inch L/B module 8PCS -C(Nitride 3043_INX_V650HP1-PS6) G Assembly Pull EA 4
4 1 9LE 170109004030 DIFFUSER SHEET UP-CELL1(CH194K/PET 0.265t)(LC-65LE643U) G Assembly Pull EA 1
4 1 9LE 170109004100 DIFFUSER PLATE(EMS-55K3/PS 2t)(LC-65LE643U) G Assembly Pull EA 1
4 1 9LE 170109004340 PRISM HORIZONTAL MIDDLECELL2(HF54U3/PET 0.275t)(LC-65LE643 G Assembly Pull EA 1
4 1 9LE 170109004350 PRISM VERTICAL DOWN-CELL3(HF64U0V/PET 0.29t)(LC-65LE643U) G Assembly Pull EA 1
4 1 9LE 170109004560 REFLECTOR(225-RA/PET 0.225t)(EM65FTR) G Assembly Pull EA 1
2 1 9LE 366501620150 MAIN BD ASS'Y LC-65LE645U_V650HP1-PS6_RTD2986 (HDCP) M Assembly Pull EA 1
3 1 9LE 366501620150M MAIN BD ASS'Y LC-65LE645U_V650HP1-PS6_RTD2986 MI P Phantom EA 1
4 1 9LE 028027000213 X'TAL 27MHZ HC-49S 30PPM 20PF 18ohm + W/O PAD -20~85'C HF G Assembly Pull EA 2 Y1,YM2
4 1 9LE 030062000130 USB CONN. A TYPE 90' (3AL04S-305-ZC) L-F G Assembly Pull EA 1 PU3
4 *R* 9LE 030062000200 USB CONN. A TYPE 90' (184-0420112-AT) LF G EA 1
4 *R* 9LE 030062000051 USB CONN. A TYPE 90' (UB1112C-4K5-4F) L-F G Assembly Pull EA 1
4 1 9LE 030064000070 OPTO CONN. Transmitter (JST1221) L-F G Assembly Pull EA 1 PA1
4 *R* 9LE 030064000140 OPTO CONN. 90' Transmitter 16MB (GQ48T-01) LF G EA 1
4 1 9LE 030290200270 RCA JACK 1ROW 2I/O 90' (W-R) (WT-04066V2B-06H) L-F G Assembly Pull EA 1 PA2
4 *R* 9LE 030290200039 RCA JACK 1ROW 2I/O 90' (W-R) (RCA215D-01) LF G Assembly Pull EA 1
4 1 9LE 030290500071 RCA JACK 1R 5IO 90'(GBRWR)(WTJ-032-55V2B-01A) LF G Assembly Pull EA 1 PV1
