Sharp LC-65LE645U - Page 80

Level
Child
P/N Seq
Child P/N Specification UIT Supply Type UOM Qty Circuit Number
6 1 9LE 013010001654 RES. CF 100ohm 1/16W J 0402 G Assembly Pull EA 50
R26,R28,RA32,RA53,RA54,RA65,RH29,RH33,RI15,RI17,RI18,RI20
,RM1,RM10,RM11,RM12,RM163,RM2,RM3,RM4,RM5,RM6,RM65,
RM66,RM7,RM79,RM8,RM80,RM81,RM82,RM83,RM84,RM85,RM8
6,RM87,RM88,RM9,RP10,RP13,RP20,RP21,RT18,RT19,RU20,RV
10,RV2,RV4,RV5,RV8,RV9
6 1 9LE 013010011459 RES. CF 1.0Kohm 1/4W J 1206 G Assembly Pull EA 2 RL2,RP40
6 1 9LE 013010011654 RES. CF 1Kohm 1/16W J 0402 G Assembly Pull EA 7 RH56,RH59,RL5,RM115,RM117,RM124,RP55
6 1 9LE 013010020055 RES. CF 10Kohm 1/10W J 0603 G Assembly Pull EA 2 RV16,RV17
6 1 9LE 013010021654 RES. CF 10Kohm 1/16W J 0402 G Assembly Pull EA 32
RA23,RA26,RA42,RA56,RA69,RA92,RH68,RH69,RL107,RL3,RL6,
RL7,RL8,RM126,RM153,RM154,RM167,RM168,RM177,RM178,RM
186,RM97,RP11,RP12,RP14,RP57,RP61,RP62,RP65,RP79,RT27,
RU21
6 1 9LE 013010031654 RES. CF 100Kohm 1/16W J 0402 G Assembly Pull EA 1 RA68
6 1 9LE 013010041654 RES. CF 1Mohm 1/16W J 0402 G Assembly Pull EA 1 RI9
6 1 9LE 013010091654 RES. CF 10ohm 1/16W J 0402 G Assembly Pull EA 2 RU18,RU19
6 1 9LE 013010091859 RES. CF 10ohm 1/8W J 1206 G Assembly Pull EA 1 RI14
6 1 9LE 013012031654 RES. CF 120Kohm 1/16W J 0402 G Assembly Pull EA 1 RP74
6 51 9LE 013018010055 RES. CF 1.8Kohm 1/10W J 0603 G Assembly Pull EA 1 RL22
6 1 9LE 013022001858 RES. CF 220ohm 1/8W J 0805 G Assembly Pull EA 1 RA91
6 1 9LE 013022031654 RES. CF 220Kohm 1/16W J 0402 G Assembly Pull EA 1 RI5
6 1 9LE 013022091654 RES. CF 22ohm 1/16W J 0402 G Assembly Pull EA 13
R51,R52,R53,R54,R55,R56,R59,RA35,RA39,RA40,RA41,RA46,RA
57
6 1 9LE 013024021654 RES. CF 24 Kohm 1/16W J 0402 G Assembly Pull EA 1 RP78
6 1 9LE 013033001654 RES. CF 330ohm 1/16W J 0402 G Assembly Pull EA 1 RI13
6 1 9LE 013033081858 RES. CF 3.3ohm 1/8W J 0805 G Assembly Pull EA 4 RA10,RA7,RA8,RA9
6 1 9LE 013033090055 RES. CF 33ohm 1/10W J 0603 G Assembly Pull EA 4 RA47,RA51,RA80,RA81
6 81 9LE 013033091654 RES. CF 33ohm 1/16W J 0402 G Assembly Pull EA 1 RH58
6 1 9LE 013039021654 RES. CF 39 Kohm 1/16W J 0402 G Assembly Pull EA 1 R31
6 1 9LE 013047000055 RES. CF 470ohm 1/10W J 0603 G Assembly Pull EA 4 RA37,RA38,RA72,RA73
6 1 9LE 013047011654 RES. CF 4.7Kohm 1/16W J 0402 G Assembly Pull EA 14
R414,R420,R443,RA18,RA45,RH22,RH23,RH37,RM107,RMP15,R
MP8,RS7,RT20,RT21
6 1 9LE 013047021654 RES. CF 47Kohm 1/16W J 0402 G Assembly Pull EA 6 RA49,RA66,RA78,RA79,RH65,RP59
6 1 9LE 013047031654 RES. CF 470Kohm 1/16W J 0402 G Assembly Pull EA 2 RA50,RL4
6 1 9LE 013068010055 RES. CF 6.8Kohm 1/10W J 0603 G Assembly Pull EA 2 RV13,RV15
6 1 9LE 013068021654 RES. CF 68Kohm 1/16W J 0402 G Assembly Pull EA 1 RP17
6 1 9LE 013075090055 RES. CF 75ohm1/10W J 0603 G Assembly Pull EA 5 RN3,RN4,RV3,RV6,RV7
6 1 9LE 013110011614 RES. MF 1K ohm 1/16W F 0402 G Assembly Pull EA 3 R418,R421,RT22
6 1 9LE 013110021614 RES. MF 10Kohm 1/16W F 0402 G Assembly Pull EA 7 R405,RMP13,RMP14,RMP9,RP64,RP69,RP73
6 1 9LE 013110031614 RES. MF 100Kohm 1/16W F 0402 G Assembly Pull EA 1 RP68
6 1 9LE 013112021614 RES. MF 12.0Kohm 1/16W F 0402 L-F G Assembly Pull EA 2 RMP10,RMP16
6 1 9LE 013112031614 RES. MF 120K ohm 1/16W F 0402 G Assembly Pull EA 1 RMP1
6 1 9LE 013112431614 RES. MF 124Kohm 1/16W F 0402 G Assembly Pull EA 1 RP86
6 21 9LE 013113321614 RES. MF 13.3Kohm 1/16W F 0402 G Assembly Pull EA 1 RP76
6 1 9LE 013115021614 RES. MF 15.0 K ohm 1/16W F 0402 G Assembly Pull EA 2 RA74,RA77
